MARTIN SPROCKET 140R18H Sprocket, 140 Chain, 18 Teeth, 10.078 Inch Pitch Dia., 10.975 Inch O.D., Steel
Get it by Tuesday, Jun 17
€687.01 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | Roller Chain Sprocket |
| Bore Type | Bushed Bore |
| Bushing Part Number | R1 |
| Chain Number | 140 |
| Chain Pitch | 1 3/4" |
| Construction | Welded |
| For Chain Number | 140 |
| For Chain Pitch | 1 3/4" |
| Hardened Teeth | 1 |
| Hub Configuration | B |
| Hub Outside Dia. | 5 1/2" |
| Individually Packaged | No |
| Keyway Size | 3/4" |
| Length Through Bore | 2" |
| Material | Steel |
| Max. Bore Size | 3 3/4" |
| Min. Bore Size | 1 1/8" |
| Number Of Chain Rows | 1 |
| Number Of Teeth | 18 |
| Outside Dia. | 10.975" |
| Pitch Dia. | 10.0778" |
| Single Strand Tooth Thickness | 0.924" |
| Storage Dimension Height | 2" |
| Storage Dimension Length | 10.975" |
| Storage Dimension Width | 10.975" |
| Weight | 20 lbs. |
| Ship weight (kg) | 8.62 |
| Ship height (cm) | 7.32 |
| Ship length (cm) | 27.89 |
| Ship width (cm) | 27.89 |
