LEESON 5KH39QN5525 4355 / 5KH39QN5525M Fan and Blower Motor, 0.25 HP, 1 Phase, 60 Hz, 115V, 1800 RPM
Get it by Monday, Jun 16
€254.97 /unit
Add To Cart
Request a Quote
Payment
Get it by Monday, Jun 16
Payment
| Item | HVAC Motor |
| Ambient Temp. | 40°C |
| Duty Cycle | Continuous |
| Frame | 48 |
| Frequency | 60 Hz |
| Full Load Amps | 5.1A |
| Hp | 1/4 hp |
| Insulation Class | Class B |
| Motor Enclosure Design | Dripproof |
| Motor Mounting Position | All Angle |
| Motor Shaft Rotation | CCW |
| Motor Thermal Protection | No |
| Motor Type | Split Phase |
| Mounting Type | Resilient Base |
| Nameplate Rpm | 1725 RPM |
| Number Of Speeds | 1 |
| Orientation | Horizontal/Vertical |
| Phase | 1 |
| Service Factor | 1.35 |
| Shaft Dia. | 1/2" |
| Shaft Length | 1 1/2" |
| Thermal Protection | None |
| Voltage | 115V AC |
| Ship weight (kg) | 5.85 |
| Ship height (cm) | 14.81 |
| Ship length (cm) | 22.68 |
| Ship width (cm) | 14.38 |
| HS code | 8501404040 |
| Country of Origin | MX |
| Product | Model | Enclosure | Frame | Full Load Amps | HP | Item | Rotation | Thermal Protection | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
 |
5KH39QN5514T | Open | 48Y | 6.6 | 1/3 | HVAC Motor | Counterclockwise | Automatic | €237.06 | |
 |
5KH32DN5618T | Open | 48Y | 5.1 | 1/4 | General Purpose Motor | Clockwise | Automatic | €230.88 |
