LEESON 145THTN17034 Y285 / 145THTN17034AA Plus Inverter Duty Encoder Motor, 2 HP, 3 Phase, 60 Hz, 230/460V, 1800 RPM
Get it by Tuesday, Jun 17
€2,446.06 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | Vector Motor |
| Ambient Temp. | 40°C |
| Application | Crane |
| Base Type | Rigid Base |
| Bearing Type | Ball |
| Color | Black |
| Conduit Box Position | F1/F2 Capable |
| Constant Torque | 1000:1 |
| Design | A |
| Duty Cycle | Continuous |
| Efficiency | 82.5% |
| Efficiency Group | Epact |
| Encoder Acceptable | Yes |
| Encoder Shaft Dimension | 5/8" x 1 3/4" |
| Frame | 145TC |
| Frame Material | Cast Iron |
| Frequency | 60 Hz |
| Full Load Amps | 6/3A |
| Full Load Torque | 6 lbs.-ft. |
| Hp | 2 hp |
| Insulation Class | Class H |
| Insulation Feature | CR200 Magnet Wire |
| Length Less Shaft | 12.812" |
| Max. Operating Frequency | 120 Hz |
| Max. Rpm | 5400 RPM |
| Motor Enclosure Design | Totally Enclosed Non Ventilated |
| Motor Mounting Position | Horizontal |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Motor Thermal Protection | No |
| Motor Type | Three Phase |
| Mounting Type | Face, Base |
| Nameplate Rpm | 1750 RPM |
| Nominal Efficiency | 85.5% |
| Number Of Speeds | 1 |
| Overall Length | 14 11/16" |
| Phase | 3 |
| Rpm Range | 1701-1800 RPM |
| Service Factor | 1 |
| Shaft Dia. | 7/8" |
| Shaft Length | 2 1/8" |
| Speed Ratio | 1000:1 |
| Thermal Protection | None |
| Usable @ 200v | No |
| Usable @ 208v | No |
| Voltage | 230/460V AC |
| Warranty | 3 yrs. |
| Encoder Shaft Dimensions | 5/8" x 1 3/4" |
| Finish | Black |
| Hz | 60 Hz |
| Ins. Class | Class H |
| Max. Ambient Temp. | 104°F |
| Max. Speed | 5400 RPM |
| Motor Application | Crane |
| Motor Bearings | Ball |
| Motor Design | 3-Phase |
| Motor Frame Material | Cast Iron |
| Motor Mounting Type | Rigid Base |
| Motor Service Factor | 1 |
| Nema Design | NEMA A |
| No. Of Speeds | 1 |
| Speed Range | 1000:1 |
| Standards | CE, UL RECOGNIZED |
| Torque | 6 lbs.-ft. |
| Weight | 74 lbs. |
| Ship weight (kg) | 33.3 |
| Ship height (cm) | 35.56 |
| Ship length (cm) | 57.15 |
| Ship width (cm) | 42.7 |
| HS code | 8501524000 |
| Country of Origin | MX |
| Product | Model | Base | Efficiency Group | Enclosure | Frame | Frame Material | Full Load Amps | HP | kW | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
145THTR15540 | Removable | Standard | Totally Enclosed Nonventilated | 145TC | Rolled Steel | 4.8/2.4 | 1.5 | - | €1,823.40 | |
 |
056H17T15528 | - | - | TENV | 56C | - | 2.4/1.2 | 3/4 | 0.56 | €1,626.74 | |
 |
056H17T15526 | - | - | TENV | 56C | - | 1.6/.8 | 1/2 | 0.37 | €1,554.34 | |
 |
143THTR15535 | - | - | TENV | 143TC | - | 3/1.5 | 1 | 0.75 | €1,853.29 | |
 |
056H17T15527 | - | - | TENV | 56C | - | 3/1.5 | 1 | 0.75 | €1,722.40 |
