LEESON 056H17T15526 Y280 / 56H17T15526A Plus Inverter Duty Encoder Motor, 0.50 HP, 3 Phase, 60 Hz, 230/460V, 1800 RPM
Get it by Tuesday, Jun 17
€1,554.34 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | Vector Motor |
| Ambient Temp. | 40°C |
| Application | Crane |
| Assembly | F1 Only |
| Color | Black |
| Conduit Box Position | F1 Only |
| Constant Torque | 1000:1 |
| Design | A |
| Duty Cycle | Continuous |
| Efficiency | 80% |
| Encoder Acceptable | Yes |
| Encoder Shaft Dimensions | 5/8" x 1 3/4" |
| Frame | 56C |
| Frame Material | Steel |
| Frequency | 60 Hz |
| Full Load Amps | 1.6/0.8A |
| Full Load Efficiency | 80% |
| Full Load Torque | 1.5 lbs.-ft. |
| Hp | 1/2 hp |
| Insulation Class | Class H |
| Length Less Shaft | 11.688" |
| Max. Ambient Temp. | 40°C |
| Max. Operating Frequency | 120 Hz |
| Max. Speed | 5400 RPM |
| Motor Bearings | Ball |
| Motor Design | Three Phase |
| Motor Enclosure Design | Totally Enclosed Non Ventilated |
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Cradle |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Motor Thermal Protection | No |
| Motor Type | Squirrel Cage Inverter Rated |
| Mounting Type | C Face, Removable Base |
| Nameplate Rpm | 1725 RPM , 1800 RPM |
| Nema Design | A |
| Nominal Efficiency | 80% |
| Number Of Speeds | 1 |
| Orientation | Horizontal |
| Overall Length | 13 3/4" |
| Phase | 3 |
| Power | 0.37 kW |
| Service Factor | 1 |
| Shaft Dia. | 5/8" |
| Shaft Length | 2.062" |
| Speed Range | 1000:1 |
| Usable @ 200v | No |
| Usable @ 208v | No |
| Voltage | 230/460V AC |
| Finish | Black |
| Hz | 60 Hz |
| Ins. Class | Class H |
| Motor Application | Crane |
| Motor Frame Material | Steel |
| Motor Service Factor | 1 |
| No. Of Speeds | 1 |
| Standards | CE, UL RECOGNIZED |
| Torque | 1.5 lbs.-ft. |
| Weight | 29 lbs. |
| Ship weight (kg) | 13.05 |
| Ship height (cm) | 31.27 |
| Ship length (cm) | 50.01 |
| Ship width (cm) | 32.05 |
| HS code | 8501514040 |
| Country of Origin | MX |
| Product | Model | Base | Efficiency Group | Enclosure | Frame | Frame Material | Full Load Amps | HP | kW | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
145THTR15540 | Removable | Standard | Totally Enclosed Nonventilated | 145TC | Rolled Steel | 4.8/2.4 | 1.5 | - | €1,823.40 | |
 |
145THTN17034 | Rigid | Epact | Totally Enclosed Nonventilated | 145TC | Cast Iron | 6.0/3.0 | 2 | - | €2,446.06 | |
 |
056H17T15528 | - | - | TENV | 56C | - | 2.4/1.2 | 3/4 | 0.56 | €1,626.74 | |
 |
143THTR15535 | - | - | TENV | 143TC | - | 3/1.5 | 1 | 0.75 | €1,853.29 | |
 |
056H17T15527 | - | - | TENV | 56C | - | 3/1.5 | 1 | 0.75 | €1,722.40 |
