LEESON 143TTFR16053 E2001A / 143TTFR16053AA General Purpose Motor, 1 HP, 3 Phase, 60/50 Hz, 230/460 and 190/380V, 1800 and 1500 RPM
Get it by Tuesday, Jun 17
€796.38 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | General Purpose Motor |
| Ambient Temp. | 40°C |
| Conduit Box Position | F3 |
| Duty Cycle | Continuous |
| Efficiency | 85.5% |
| Frame | 143TC |
| Frequency | 60 Hz |
| Full Load Amps | 1.65/3.3A |
| Hp | 1 hp |
| Insulation Class | Class F |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Rigid Base |
| Motor Type | Squirrel Cage Inverter Rated |
| Mounting Type | C Face, Rigid Base |
| Nameplate Rpm | 1800 RPM |
| Nema Design | A |
| Phase | 3 |
| Power | 0.75 kW |
| Service Factor | 1.15 |
| Voltage | 208-230/460V AC |
| Ship weight (kg) | 19.35 |
| Ship height (cm) | 23.83 |
| Ship length (cm) | 39.37 |
| Ship width (cm) | 31.12 |
| HS code | 8501524000 |
| Country of Origin | MX |
| Product | Model | Frame | Full Load Amps | HP | Hz | kW | Mounting | Price | |
|---|---|---|---|---|---|---|---|---|---|
 |
056T34F5940 | 56C | 3-2.8/1.4 | 1 | 50/60 | - | Face/Base | €976.65 | |
 |
145TTFR16329 | 145TC | 6.2-6/3 | 2 | 60 | 1.49 | C-Face Rigid | €898.86 |
