LEESON 056T34F5940 E2000 / 56T34F5940B General Purpose Motor, 1 HP, 3 Phase, 60/50 Hz, 208-230/460 and 190/380V, 3600 RPM
Get it by Tuesday, Jun 17
€976.65 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | General Purpose Motor |
| Ambient Temp. | 40°C |
| Base Type | Rigid Base |
| Bearing Type | Ball |
| Capacitor Required | No |
| Cc Number | CC003A |
| Duty Cycle | Continuous |
| Efficiency | 80% |
| Efficiency Group | NEMA Premium |
| Frame | 56C |
| Frame Material | Rolled Steel |
| Frequency | 50/60 Hz |
| Full Load Amps | 2.8-3/1.4A |
| Full Load Amps @ 50hz | 2.8-3/1.4A |
| Hp | 1 hp |
| Insulation Class | Class F |
| Inverter Rated | Yes |
| Length Less Shaft | 9 5/8" |
| Max. Ambient Temp. | 104°F |
| Motor Application | General Application |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Mounting Position | Horizontal |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Motor Type | Three Phase |
| Mounting Type | Face, Base |
| Nameplate Rpm | 3490 RPM |
| No. Of Speeds | 1 |
| Overall Length | 11 11/16" |
| Phase | 3 |
| Rpm Range | 3001-3600 RPM |
| Service Factor | 1.15 |
| Shaft Dia. | 5/8" |
| Shaft Length | 2 1/16" |
| Thermal Protection | None |
| Usable @ 200v | No |
| Usable @ 208v | Yes |
| Voltage | 208-230/460V AC |
| Warranty | 1 yr. |
| Hp @ 50hz | 1 hp |
| Hz | 50/60 Hz |
| Ins. Class | Class F |
| Manufacturers Warranty Length | 1 yr. |
| Motor Bearings | Ball |
| Motor Design | 3-Phase |
| Motor Frame Material | Steel |
| Motor Mounting Type | Rigid Base |
| Motor Service Factor | 1.15 |
| Motor Thermal Protection | None |
| Nominal Efficiency | 80% |
| Standards | CSA, UL RECOGNIZED |
| Weight | 28 lbs. |
| Ship weight (kg) | 11.21 |
| Ship height (cm) | 27.64 |
| Ship length (cm) | 36.68 |
| Ship width (cm) | 26.52 |
| HS code | 8501524000 |
| Country of Origin | US |
| Product | Model | Frame | Full Load Amps | HP | Hz | kW | Mounting | Price | |
|---|---|---|---|---|---|---|---|---|---|
 |
145TTFR16329 | 145TC | 6.2-6/3 | 2 | 60 | 1.49 | C-Face Rigid | €898.86 | |
 |
143TTFR16053 | 143TC | 3.3-3.3/1.65 | 1 | 60 | 0.75 | C-Face Rigid | €796.38 |
