LEESON 056B17D11014 56B17D11014A / G230A General Purpose Motor, 0.33 HP, 1 Phase, 60 Hz, 115/230V, 1800 RPM
Get it by Tuesday, Jun 17
€469.80 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | General Purpose Motor |
| Bearing Type | Ball |
| Cc Number | CC003A |
| Duty Cycle | Continuous |
| Frame | 56C |
| Frame Material | Steel |
| Hp | 1/3 hp |
| Hz | 60 Hz |
| Insulation Class | Class B |
| Inverter Rated | No |
| Length Less Shaft | 8 7/8" |
| Max. Ambient Temp. | 40°C |
| Motor Application | General Application |
| Motor Design | Capacitor Start/Run |
| Motor Enclosure Design | Open Dripproof |
| Motor Mounting Position | Horizontal |
| Motor Shaft Design | Flat |
| Motor Shaft Rotation | CW/CCW |
| Motor Thermal Protection | No |
| Mounting Type | Face |
| Nameplate Rpm | 1725 RPM |
| Nominal Efficiency | 72.4% |
| Number Of Speeds | 1 |
| Overall Length | 10 15/16" |
| Phase | 1 |
| Service Factor | 1.35 |
| Shaft Dia. | 5/8" |
| Shaft Length | 2 1/16" |
| Usable @ 200v | No |
| Usable @ 208v | No |
| Voltage | 115/230V AC |
| Full Load Amps | 3.8/1.9A |
| Ins. Class | Class B |
| Motor Bearings | Ball |
| Motor Frame Material | Steel |
| Motor Mounting Type | Face |
| Motor Service Factor | 1.35 |
| No. Of Speeds | 1 |
| Standards | CE, CSA, UL RECOGNIZED |
| Weight | 19 lbs. |
| Ship weight (kg) | 8.55 |
| Ship height (cm) | 18.42 |
| Ship length (cm) | 29.85 |
| Ship width (cm) | 14.61 |
| HS code | 8501404040 |
| Country of Origin | MX |
