LEESON 048A17T96 X468 / 48A17T96D Condenser Fan Motor, 0.50 HP, 1 Phase, 60 Hz, 208-230V, 1800 RPM
Get it by Tuesday, Jun 17
€318.55 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | HVAC Motor |
| Ambient Temp. | 40°C |
| Assembly | F1 Only |
| Design | No Design Code |
| Duty Cycle | Continuous |
| Efficiency | 71.7% |
| Enclosure Type | Totally Enclosed Air Over |
| Frame | 48Z |
| Full Load Amps | 2.6-2.9A |
| Hp | 1/2 hp |
| Motor Enclosure Design | Totally Enclosed Air Over |
| Motor Mounting Type | Extended Studs Footless |
| Motor Shaft Rotation | Selective Counter Clockwise |
| Motor Thermal Protection | Automatic |
| Mounting Type | Extended Studs, Footless |
| Nema Design | No Design Code |
| Phase | 1 |
| Power | 0.37 kW |
| Rpm | 1625 RPM |
| Service Factor | 1 |
| Shaft Orientation | Horizontal |
| Thermal Protection | Automatic |
| Voltage | 208-230V AC |
| Ship weight (kg) | 7.2 |
| Ship height (cm) | 16.81 |
| Ship length (cm) | 40.79 |
| Ship width (cm) | 17.15 |
| HS code | 8501404040 |
| Country of Origin | MX |
| Product | Model | Duty | Enclosure | Frame | Full Load Amps | HP | kW | Mounting | NEMA Design | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
048A11T569 | CONTINUOUSAOM | TEAO | 48Y | 1.4 | 1/4 | 0.19 | Extended Studs - Footless | N | €279.66 | |
 |
048A11T619 | CONT.AOM | TENV | 48Y | 3.4 | 1 | 0.75 | Round | NO DES CODE | €449.43 | |
 |
048A11T581 | CONT.AOM | TEAO | 48Y | 2.1 | 3/4 | 0.56 | Extended Studs - Footless | NO DESIGN CODE | €430.30 | |
 |
048A11T571 | CONTINUOUS AOM | TEAO | 48Z | 2.75-2.7 | 1/2 | 0.37 | Extended Studs - Footless | N | €333.36 | |
 |
048A11T2020 | CONT.AOM | TEAO | 48Y | 1.3 | 1/6 | 0.13 | Extended Studs - Footless | NO DESIGN CODE | €92.50 | RFQ
|
 |
048A11T580 | CONT.AOM | TEAO | 48Y | 1.4 | 1/2 | 0.37 | Extended Studs - Footless | NO DESIGN CODE | €368.56 | |
 |
048A17T86 | CONTINUOUSAOM | TEAO | 48Y | 2 | 1/3 | 0.25 | Extended Studs - Footless | NO DESIGN CODE | €286.45 |
