LEESON 048A11T569 X412 / 48A11T569F Condenser Fan Motor, 0.25 HP, 1 Phase, 60 Hz, 208-230V, 1200 RPM
Get it by Tuesday, Jun 17
€279.66 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | HVAC Motor |
| Ambient Temp. | 60°C |
| Assembly | F1 Only |
| Bearing Type | Ball |
| Body Dia. | 5.688" |
| Bolt Circle Dia. | 5.312" |
| Capacitor Required | Yes |
| Conduit Box Location | Exterior |
| Conduit Box Position | F1 Only |
| Design | N |
| Duty Cycle | Continuous |
| Efficiency | Not Applicable |
| Enclosure Type | Totally Enclosed Air Over |
| Extended Thru-bolts | Yes |
| Features | Shaft Slinger, Thru Bolt, Weather Resistant Reversing Plug |
| Frame | 48Y |
| Frame Material | Steel |
| Frequency | 60 Hz |
| Full Load Amps | 1.4A |
| Hp | 1/4 hp |
| Insulation Class | Class B |
| Lead Length | 30" |
| Length Less Shaft | 4 3/4" |
| Max. Ambient Temp. | 60°C |
| Motor Application | HVAC/R |
| Motor Design | Permanent Split Capacitor |
| Motor Enclosure Design | Totally Enclosed Air Over |
| Motor Mounting Position | Horizontal, Vertical Shaft Up |
| Motor Mounting Type | Extended Studs |
| Motor Shaft Design | Double Flat |
| Motor Shaft Rotation | Selective Counter Clockwise |
| Motor Sub Application | Condenser Fan |
| Motor Thermal Protection | Automatic |
| Motor Type | Permanent Split Capacitor |
| Mounting Stud Pattern | 3 5/8" x 3 5/8" |
| Mounting Type | Extended Studs, Footless |
| Nameplate Rpm | 1075 RPM |
| Nema Design | N |
| Nominal Efficiency | 68.50% |
| Number Of Speeds | 1 |
| Number Of Studs | 4 |
| Overall Length | 10 3/4" |
| Phase | 1 |
| Power | 0.19 kW |
| Removable Base | No |
| Service Factor | 1 |
| Shaft Dia. | 1/2" |
| Shaft Length | 6" |
| Shaft Orientation | Horizontal |
| Stud Size | #8-32 |
| Thermal Protection | Automatic |
| Usable @ 200v | No |
| Usable @ 208v | Yes |
| Voltage | 208-230V AC |
| Warranty | 1 yr. |
| Hz | 60 Hz |
| Ins. Class | Class B |
| Manufacturers Warranty Length | 1 yr. |
| Motor Bearings | Ball |
| Motor Frame Material | Steel |
| Motor Service Factor | 1 |
| No. Of Speeds | 1 |
| Output Watts | 190 W |
| Standards | CSA CERTIFIED, UL RECOGNIZED |
| Stud Quantity | 4 |
| Weight | 12 lbs. |
| Ship weight (kg) | 5.4 |
| Ship height (cm) | 17.63 |
| Ship length (cm) | 33.66 |
| Ship width (cm) | 17.78 |
| HS code | 8501404040 |
| Country of Origin | MX |
| Product | Model | Duty | Enclosure | Frame | Full Load Amps | HP | kW | Mounting | NEMA Design | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
048A11T619 | CONT.AOM | TENV | 48Y | 3.4 | 1 | 0.75 | Round | NO DES CODE | €449.43 | |
 |
048A17T96 | CONTINUOUS AOM | TEAO | 48Z | 2.9-2.6 | 1/2 | 0.37 | Extended Studs - Footless | NO DESIGN CODE | €318.55 | |
 |
048A11T581 | CONT.AOM | TEAO | 48Y | 2.1 | 3/4 | 0.56 | Extended Studs - Footless | NO DESIGN CODE | €430.30 | |
 |
048A11T571 | CONTINUOUS AOM | TEAO | 48Z | 2.75-2.7 | 1/2 | 0.37 | Extended Studs - Footless | N | €333.36 | |
 |
048A11T2020 | CONT.AOM | TEAO | 48Y | 1.3 | 1/6 | 0.13 | Extended Studs - Footless | NO DESIGN CODE | €92.50 | RFQ
|
 |
048A11T580 | CONT.AOM | TEAO | 48Y | 1.4 | 1/2 | 0.37 | Extended Studs - Footless | NO DESIGN CODE | €368.56 | |
 |
048A17T86 | CONTINUOUSAOM | TEAO | 48Y | 2 | 1/3 | 0.25 | Extended Studs - Footless | NO DESIGN CODE | €286.45 |
