| Item | General Purpose Motor |
| Ambient Temp. | 104°F |
| Base Type | Rigid Base |
| Bearing Type | Ball |
| Cc Number | CC029A |
| Composition | Cast Iron |
| Duty Cycle | Continuous |
| Efficiency | 95.4% |
| Efficiency Group | Premium |
| Frame | 405T |
| Frame Material | Cast Iron |
| Frequency | 60 Hz |
| Full Load Amps | 301-284/142A |
| Full Load Amps @ 50hz | 129/133/138A |
| Green Certification Or Other Recognition | NEMA Premium Rated |
| Hp | 125 hp |
| Insulation Class | Class F |
| Motor Application | General Application |
| Motor Enclosure Design | Open Dripproof |
| Motor Mounting Position | Horizontal |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | Clockwise/Counter Clockwise |
| Motor Type | Three Phase |
| Mounting Type | Rigid Base |
| Nameplate Rpm | 1780 RPM |
| Nema Design | B |
| No. Of Speeds | 1 |
| Overall Length | 34 1/8" |
| Phase | 3 |
| Rpm Range | 1701-1800 RPM |
| Service Factor | 1.15 |
| Shaft Dia. | 2 7/8" |
| Shaft Length | 7 1/4" |
| Ships Factory Direct | No |
| Thermal Protection | None |
| Usable @ 200v | No |
| Usable @ 208v | Yes |
| Warranty | 3 yrs. |
| Ship weight (kg) | 487.8 |
| Ship height (cm) | 96.27 |
| Ship length (cm) | 107.95 |
| Ship width (cm) | 160.78 |
| HS code | 8501534080 |
| Country of Origin | BR |
