| Item | Pneumatic Vibrator |
| Bin Weight Capacity | 4000 lbs. |
| Duty | Continuous |
| Force Rating | 585 lbs. |
| Housing Material | Steel |
| Inlet Port Size | 1/4" |
| Inlet Port Type | NPT |
| Max. Pressure | 80 psi |
| Mounting | Foot |
| Mounting Plate | Sold Separately |
| Outlet Port | 1/4" NPT |
| Overall Height | 7.938" |
| Overall Length | 7 1/2" |
| Overall Width | 3" |
| Speed @ 60 Psi | 4000 VPM |
| Speed @ 80 Psi | 5200 VPM |
| Vibrator Type | Piston |
| Air Flow Rate | 6.5 CFM @ 40 psi, 9 CFM @ 60 psi, 11 CFM @ 80 psi |
| Application | Chemical Plants, Foundries And Paper Plants, Manufacturing, Mining, Plastics |
| Compatible Muffler Grainger Part Number | 1A326 |
| Duty Cycle | Continuous |
| Force @ Psi | 585 lbf. @ 80 psi |
| Inlet Connection | 1/4" NPT |
| Maximum Inlet Pressure | 80 psi |
| Maximum Vibration Speed | 5200 VPM |
| Mount Type | Bolt On |
| Outlet Connection | 1/4" NPT |
| Pneumatic Vibrator Type | Piston |
| Series | 50 Series |
| Sound Level | 95 dbA |
| Standards | CE CERTIFIED |
| Vibration Speeds @ Psi | 2800 vpm @ 40 psi, 4000 vpm @ 60 psi, 5200 vpm @ 80 psi |
| Weight | 16 lbs. |
| Ship weight (kg) | 7.27 |
| Ship height (cm) | 20.19 |
| Ship length (cm) | 19.1 |
| Ship width (cm) | 7.59 |
| HS code | 8479899895 |
| Country of Origin | US |
| Model | Overall Height | Overall Length | Overall Width | Price | |
|---|---|---|---|---|---|
| 50-1 | 4 9/16" | 4.5" | 2" | €365.75 | |
| 50-1-1/2-EM | 7 15/16" | 7.5" | 3" | €691.75 | |
| 50-1-1/2S | 7 15/16" | 7.5" | 3" | €516.90 | |
| 50-1-1/2S-EM | 7 15/16" | 7.5" | 3" | €741.53 | |
| 50-1-1/4 | 6.375" | 6" | 2.5" | €532.95 | |
| 50-1-1/4-EM | 6.375" | 6" | 2.5" | €798.73 | |
| 50-1-1/4S | 6.375" | 6" | 2.5" | €515.78 |
