| Ability To Relubricate | No |
| Across Wrench Flats | 0.312" |
| Axial Load | 185 |
| Ball Diameter | 0.437" |
| Ball Finish | Chrome Plated |
| Ball Flat Diameter | 0.306" |
| Ball Material | Alloy Steel |
| Ball Width | 0.312" |
| Base Diameter | 3/8" |
| Bearing Insert Type | Rod End |
| Bore Dia. | 3/16" |
| Class | Commercial |
| Configuration | Female |
| Construction | Three Piece Rod End with Y Stud |
| Head Diameter | 5/8" |
| Housing Style | Female Rod End |
| Housing Width | 1/4" |
| Htc | 8483.30.8055 |
| Length To Center Of Ball | 1.06" |
| Lubrication | No Zerk Fitting |
| Lubrication Method | No Fitting |
| Lubrication Type | Grease |
| Max Static Radial Load | 1850 |
| Max. Ambient Temp. | 350°F |
| Misalignment Angle B3 | 27° |
| Outer Material | Carbon Steel |
| Outer Material Property | Corrosion Resistant Plating |
| Product Selection Available Sw | No |
| Product Type | TF |
| Race Material | Bronze |
| Series | Commercial |
| Stud Length To Center Of Ball | 0.97" |
| Stud Length To Hex | 1/2" |
| Stud Thread Length | 7/16" |
| Thread Direction | RH |
| Thread Length | 0.531" |
| Thread Size | #10-32 |
| Thread Type | UNF |
| Type | Female Rod End |
| Y Stud Material | Carbon Steel |
| Y Stud Material Property | corrosion resistant plating |
| Zerk Fitting Sw | No |
| Ship weight (kg) | 0.02 |
| Ship height (cm) | 2.87 |
| Ship length (cm) | 3.51 |
| Ship width (cm) | 1.6 |
| Country of Origin | MX |
