| Item | Bearing |
| Bore Dia. | 1 1/8" |
| Bore Type | Cylindrical |
| Closure Type | Double Sealed |
| Dynamic Load Capacity | 600 lbf. |
| Features | Lock Pin And Dimple For Direct Lubrication And Anti-Rotation |
| Housing Material | Steel |
| Housing Material Finish | Black Oxide |
| Housing Material Grade | 52100 |
| Housing Type | Rhombus |
| Includes | Set Screw |
| Insert Material | Alloy Steel |
| Insert Type | Radial Ball |
| Lubricant Material Class | NLGI#2 Equivalent |
| Lubrication Openings | None |
| Max. Speed | 5450 RPM |
| Max. Temp. | 220°F |
| Min. Temp. | -20°F |
| Mount Hole Center-to-center Height | 4 3/8" |
| Mount Hole Center-to-center Length | 4 3/8" |
| Mount Hole Size | 1/2" |
| Mounting Bolt Size | 0.438" |
| Number Of Mounting Holes | 2 |
| Overall Height | 3 1/2" |
| Overall Length | 5 3/8" |
| Overall Width | 1.656" |
| Rolling Element Rows | 1 |
| Seal Material | Felt |
| Seal Type | Contact |
| Self Lubricating Bearing | No |
| Shaft Locking Type | Set Screws |
| Static Radial Load Capacity | 360 lbf. |
| Bearing Insert Material | Alloy Steel |
| Bearing Insert Type | Radial Ball |
| Bearing Material Grade | Grade 52100 |
| Bore Diameter | 1 1/8" |
| Closure | Double Sealed |
| Expansion Type | Fixed |
| Lubricant Material | NLGI #2 Equivalent |
| Maximum Speed | 5450 RPM |
| Maximum Temperature | 220°F |
| Minimum Temperature | -20°F |
| Number Of Mount Holes | 2 |
| Ship weight (kg) | 0.68 |
| Ship height (cm) | 8.89 |
| Ship length (cm) | 13.65 |
| Ship width (cm) | 4.21 |
