| 20 | $270.86 |
| 60 | $225.72 |
| Bore (b1) | 1.1250 in |
| Bore Tolerance | +0.0020 in / +0.0005 in |
| Clearance Diameter (c) Max | 2.140 in |
| Finish Specification | Bright, No Plating |
| Forged Clamp Screw | 1/4-28 |
| Hex Wrench Size | 3/16 in |
| Keyway (k1) | 1/4 in |
| Keyway (k2) | 1/4 in |
| Length (l) | 1 1/16 in |
| Material Specification | Type 303 Austenitic, Non-Magnetic Bar |
| Moment Of Inertia | 0.2979 lb-in |
| Number Of Screws | 4 ea |
| Outer Diameter (od) | 1 7/8 in |
| Recommended Gap | 0.094 in |
| Recommended Hex Key | Inch Hex Keys |
| Recommended Shaft Tolerance | +0.0000 in / -0.0005 in |
| Screw Finish | Bright |
| Screw Location (r) | 0.748 in |
| Screw Material | 18-8 300 Series Stainless Steel |
| Seating Torque | 110 lb-in |
| Small Bore (b2) | 1.0000 in |
| Temperature | -40°F to 350°F (-40°C to 176°C) |
| Torque Wrench | TW:BT-4C-3/8-110 |
| Width (w) | 1 1/16 in |
| Ship weight (kg) | 0.23 |
| Ship height (cm) | 4.76 |
| Ship length (cm) | 2.7 |
| Ship width (cm) | 2.7 |
| Country of Origin | US |
