| 2 | $54.50 |
| 20 | Request Quote |
| Geometry | Cylindrical |
| Height (h1) | 0.79 in (20 mm) |
| Max Axial Load | 49.46 lb (220 N) |
| Max Deflection | 0.20 in (5.0 mm) |
| Metal Material | Zinc Plated Steel |
| Metallic Body Finish | Zinc-Plated |
| Multipack Quantity | 25 |
| Outer Diameter (od) | 0.79 in (20 mm) |
| Plate Thickness (pt) | 0.08 in (2 mm) |
| Rubber Material | Natural Rubber |
| Shore Hardness | 40A (+/- 5) |
| Spring Rate | 251.25 lb/in (44 N/mm) |
| Stud Length (ls) | 0.71 in (18 mm) |
| Tapped Hole Depth (lt) | 0.24 in (6.1 mm) |
| Thread (th) | M6 x 1.0 |
| Ship weight (kg) | 0.4 |
| Ship height (cm) | 2.01 |
| Ship length (cm) | 2.01 |
| Ship width (cm) | 2.01 |
| Country of Origin | HU |
