| 2 | $42.50 |
| 20 | Request Quote |
| Geometry | Cylindrical |
| Height (h1) | 0.39 in (10 mm) |
| Max Axial Load | 160.74 lb (715 N) |
| Max Deflection | 0.10 in (2.5 mm) |
| Metal Material | Zinc Plated Steel |
| Metallic Body Finish | Zinc-Plated |
| Multipack Quantity | 25 |
| Outer Diameter (od) | 0.59 in (15 mm) |
| Plate Thickness (pt) | 0.06 in (1.4 mm) |
| Rubber Material | Natural Rubber |
| Shore Hardness | 70A (+/- 5) |
| Spring Rate | 1655.94 lb/in (290 N/mm) |
| Stud Length (ls) | 0.39 in (10 mm) |
| Tapped Hole Depth (lt) | 0.39 in (9.9 mm) |
| Thread (th) | M4 x 0.7 |
| Ship weight (kg) | 0.15 |
| Ship height (cm) | 0.99 |
| Ship length (cm) | 1.5 |
| Ship width (cm) | 1.5 |
| Country of Origin | HU |
