| Base Diameter D1 | 50 mm |
| Base Height H2 | 12.5 mm |
| Base Width Wb | 44 mm |
| Center To Center Lc | 36 mm |
| Clamp Length L1 | 30 mm |
| Clamp Width Wc | 15 mm |
| Counterbore To Base Cb | 6.5 mm |
| Edge To Center L2 | 29.5 mm |
| Material Specification | Anodized Aluminum |
| Mounting Counterbore Diameter Mc | M6 |
| Overall Height H1 | 44.5 mm |
| Swivel Counterbore 1 Diameter S1 | 6.5 mm |
| Swivel Counterbore 2 Diameter S2 | 10.5 mm |
| Ship weight (kg) | 0.09 |
| Ship height (cm) | 4.45 |
| Ship width (cm) | 4.45 |
| Country of Origin | DE |
