| Depth | 12" |
| Height | 71" |
| Housing Color | Gray |
| Housing Material | Carbon Steel |
| Includes | Cut-Out Template At 11 Scale, Hardware Mounting Kit |
| Mounting | Wall Mount |
| Width | 18" |
| Wiring Method | Fully Wired |
| Control Type | Thermostat-Controlled |
| Cooling Capacity - Maximum | 23885 btuH |
| Cooling Method | Air, Water |
| Cooling Setpoint - Maximum | 131°F |
| Cooling Setpoint - Minimum | 68°F |
| Current | 1.4/1.61.2A |
| Environment | Indoor Dust Tight |
| Frequency | 50/60 Hz |
| Mounting Type | Wall Mount |
| Nema Enclosure Rating | 12 |
| Operating Temperature - Maximum | 158°F |
| Operating Temperature - Minimum | 34°F |
| Operating Voltage | 400/480V |
| Operation Mode | Cooling Only |
| Overall Depth | 11.81" |
| Overall Height | 70.87" |
| Overall Width | 17.72" |
| Phase | Three |
| Power Consumption | 7 kW |
| Product Type | Heat Exchanger |
| Standards | CSA |
| Ship weight (kg) | 6.75 |
| Ship height (cm) | 180.34 |
| Ship length (cm) | 30.48 |
| Ship width (cm) | 45.72 |
| Country of Origin | IT |
