| Adjustment Mechanism | Knob |
| Air Inlet Size | 1/2" |
| Air Inlet Type | NPT |
| Body Material | Zinc |
| Drain Included | Yes |
| Drain Type | Manual |
| Inlet Size | 1/2" NPT |
| Lubricator Bowl Capacity | 6 oz. |
| Lubricator Bowl Guard Included | Yes |
| Lubricator Bowl Guard Material | Steel |
| Lubricator Bowl Material | Metal |
| Lubricator Type | Mist |
| Maximum Flow Rate | 90 SCFM |
| Maximum Operating Pressure | 175 psig |
| Maximum Operating Temperature | 175°F |
| Minimum Flow Rate | 0.5 SCFM |
| Minimum Operating Pressure | 0 psig |
| Minimum Operating Temperature | 32°F |
| Overall Height | 9 1/16" |
| Overall Width | 3 1/4" |
| Pressure Drop | 5 psig |
| Recommended Lubricant | F442 Oil |
| Seal Material | Nitrile |
| Series | Series 07L |
| Sight Dome Included | Yes |
| Sight Gauge Included | Yes |
| Weight | 1.9 lbs. |
| Ship weight (kg) | 1.17 |
| Ship height (cm) | 23.02 |
| Ship width (cm) | 8.26 |
| Country of Origin | US |
