| Adjustment Mechanism | Locking Knob, Nonrising |
| Adjustment Type | Locking Knob, Nonrising |
| Body Material | Zinc |
| Bowl Material | Plastic |
| Dome Material | Polycarbonate |
| Drain Included | No |
| For Fluid Type | Compressed Air |
| For Substance Type | Air |
| Includes | Bowl, Fill Plug, Guard, Sight Dome |
| Lubricator Bowl Guard Included | Yes |
| Lubricator Bowl Guard Material | Steel |
| Lubricator Type | Mist |
| Modular Connection | Modular Connection |
| Number Of Air Inlets | 1 |
| Number Of Air Outlets | 1 |
| Oil Feed Type | Mist |
| Recommended Lubricant | F442 Oil |
| Seal Material | Nitrile Rubber |
| Sight Dome Included | Yes |
| Sight Gauge Included | Yes |
| System Location | Air Line |
| Air Inlet Size | 3/8" |
| Air Inlet Type | NPT |
| Air Outlet Size | 3/8" |
| Air Outlet Type | NPT |
| Connection Style | Air Line |
| For Maximum Pipe Run | 20 ft. |
| Inlet Size | 3/8" NPT |
| Lubricator Bowl Capacity | 2.9 oz. |
| Lubricator Bowl Material | Polycarbonate |
| Maximum Flow @ 100 Psi | 90 CFM |
| Maximum Flow Rate | 90 CFM |
| Maximum Operating Pressure | 150 psi |
| Maximum Operating Temperature | 125°F |
| Minimum Flow Rate | 40 CFM |
| Minimum Operating Pressure | 0 psig |
| Minimum Operating Temperature | 32°F |
| Oil Capacity | 2.9 oz. |
| Overall Depth | 2 3/4" |
| Overall Height | 7 13/16" |
| Overall Width | 2 3/4" |
| Pressure Drop | 5 psi |
| Series | 06L Series |
| Weight | 1.2 lbs. |
| Ship weight (kg) | 0.81 |
| Ship height (cm) | 19.84 |
| Ship length (cm) | 6.99 |
| Ship width (cm) | 6.99 |
| Country of Origin | US |
