| Item | Straight Flute Tap |
| Coolant Fed | Non Coolant Through |
| Extended Neck | Yes |
| Number Of Flutes | 4 |
| Overall Length | 3.531" |
| Primary Material Application | Aluminum, Brass, Bronze, Cast Iron, Copper |
| Secondary Material Application | Composite |
| Shank Dia. | 0.312" |
| Spiral Direction | Neutral |
| System Of Measurement | Imperial |
| Tap Chamfer | Bottoming |
| Tap Finish | Bright Uncoated |
| Tap Length Standard | DIN |
| Tap Material | High Speed Steel |
| Tap Shank Standard | ANSI |
| Tap Style | Straight Flute |
| Thread Direction | Right Hand |
| Thread Length | 5/8" |
| Thread Limit / Class Of Fit | 2B, 2B |
| Thread Size | 5/16"-24 |
| Thread Standard | Fine |
| Threads Per Inch | 24 |
| 55% Thread Drill Size | 9/32" |
| 65% Thread Drill Size | J |
| 75% Thread Drill Size | I |
| Class Of Fit | Class 2B |
| Measurement System | Fractional Inch |
| Primary Material Application Iso Code | K, N |
| Secondary Material Application Iso Code | O |
| Shank Length | 2 5/32" |
| Shank Type - Machining | Straight |
| Square Size | 0.2380" |
| Thread Limit | 2B |
| Ship weight (kg) | 0.05 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 2.54 |
| Ship width (cm) | 2.54 |
