MUELLER STEAM 3/4 125SS screwed Basket Strainer Cast Stainless Steel Body 3/4 In
€1,022.79 /unit
Request a Quote
Payment
Payment
| Item | Basket Strainer |
| Blow Off Port | 3/8" |
| Body Material | Cast Stainless Steel |
| Connection | FNPT |
| Material | Cast Stainless Steel |
| Pipe Size | 3/4" |
| Screen | Basket |
| Screen Material | Basket |
| Screen Size | 0.062" |
| Application | Chemical Processing |
| Connection Size | 3/4" |
| Connection Type | NPT |
| Cover Type | Knob |
| Drain Plug Size | 3/8" |
| For Use With | Fuel Oil |
| Gasket Material | Stainless Steel Tanged Graphite |
| Housing Material | Stainless Steel |
| Includes Screen | Yes |
| Maximum Pressure | 150 psi @ 565°F, 275 psi @ -20°F to 100°F |
| Maximum Pressure At 100°f | 285 psi |
| Maximum Temperature | 100°F |
| Mesh Number | 0.06" |
| Minimum Temperature | -20°F |
| Overall Height | 6 1/2" |
| Screen Perforation Size | 0.0620" |
| Series | 125-SS Series |
| Standards | ASTM A 351 |
| Strainer Style | Single |
| Strainer Type | Perforated |
| Ship weight (kg) | 2.18 |
| Ship height (cm) | 16.51 |
| Ship length (cm) | 11.59 |
| Ship width (cm) | 21.84 |
| HS code | 8421290065 |
| Country of Origin | US |
| Product | Model | Housing Material | Material | Max. Pressure | Price | |
|---|---|---|---|---|---|---|
 |
3/4 125 CI Iron Body Screwed | Cast iron | Cast Iron | 200 At 150 Degrees F | €494.17 |
