MACROMATIC CAP10AD68 AC Current Sensor, 5VA, Indicator Style LED, -40 to 85 Deg C
Get it by Tuesday, Jun 17
€120.30 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | AC Current Sensor |
| Amps Rating | 10A |
| Body Depth | 2.9" |
| Body Height | 2 2/5" |
| Body Width | 1.7" |
| Core Type | Internal |
| Electrical Connection | Pin , Terminal Strip |
| Electrical Phase | 3 |
| Indicator Style | LED |
| Load Capacity | 0-5 VA |
| Max. Inrush Current | 150A |
| Monitored Parameters | Overcurrent |
| Mounting - Relay | Plug In |
| No. Of Pins | 11 |
| Operating Life | 10000000 Operations |
| Overall Depth | 3 1/2" |
| Relay Mounting Style | Socket |
| Sensor Opening | Internal |
| Series | Cap Series |
| Socket Code | B |
| Temp. Range | -40°C to +85°C |
| Trip Delay | 0.1 sec. to 10 sec. |
| Trip Delay Type | Fixed |
| Trip Point Type | Adjustable |
| Contact Form | SPDT |
| Contact Rating (ac) | 10A @ 240V |
| Contact Rating (dc) | 7A @ 28V |
| Current Rating | 10A |
| Electrical Connection Type | Pin |
| Electrical Operating Durability | 100000 |
| Frequency | 50/60 Hz |
| Input Voltage | 24V AC |
| Mechanical Operating Durability | 10000000 |
| Number Of Pins/terminals | 11 |
| Standards | CULUS LISTED, CURUS |
| Status Indicator | LED Indicator |
| Trip Point | 0.1/10A |
| Ship weight (kg) | 0.2 |
| Ship height (cm) | 6.1 |
| Ship length (cm) | 7.37 |
| Ship width (cm) | 4.32 |
| Country of Origin | US |
