| Item | Fuse |
| Ac Voltage Rating | 600V AC |
| Amps | 80A |
| Body Material | Fiberglass |
| Body Style | Blade |
| Class | Class RK5 |
| Compatible Fuse Block Series | LFR |
| Dc Voltage Rating | 300V DC |
| Diameter | 1 5/16" |
| Element | Dual |
| Equivalent Brand And Series | Bussmann FRS-R, Edison ECSR, Littelfuse FLSR, Mersen TRS-R Series |
| Equivalent Series | ECSR, FLSR, FRS-R, TRS-R |
| Fits Fuse Block Style | Rejection |
| Fuse Size | 7 7/8" L x 1 5/16" dia. |
| Interrupt Rating | 200 kA at 600V AC, 20 kA at 300V DC |
| Length | 7 7/8" |
| Series | FLSR Series |
| Speed | Time Delay |
| Standards | CE, CSA CERTIFICATION, QPL-W-F-1814, UL 248-12 CLASS RK5 |
| Visual Indication | Nonindicating |
| Ship weight (kg) | 0.25 |
| Ship height (cm) | 20 |
| Ship length (cm) | 3.33 |
| Ship width (cm) | 3.33 |
| Country of Origin | MX |
