| Item | Receptacle |
| Amps | 20A |
| Body Material | Thermoplastic Nylon |
| Connection Orientation | Straight |
| Contact Material | Brass |
| Cover Type | No Cover |
| Depth | 1.06" |
| Face Plate Height | 2.38" |
| Face Plate Width | 1.31" |
| Gfci | No |
| Grounding | Grounded |
| Housing Color | Light Almond |
| Hp | 1 hp |
| Max. Operating Temp. | 60°C |
| Max. Wire Size | 10 AWG |
| Min. Operating Temp. | -40°C |
| Min. Wire Size | 14 AWG |
| Mount Hole Center-to-center Height | 3 7/25" |
| Mounting Hardware Included | Yes |
| Mounting Type | Flush |
| Nema Receptacle Configuration | NEMA 5-20R |
| Number Of Outlets | 1 |
| Number Of Poles | 2 |
| Number Of Wires | 3 |
| Polarized | Yes |
| Receptacle Type | Single |
| Voltage | 125V AC |
| Wire Connection Location | Back, Side |
| Wire Connection Type | Screw Terminals |
| Current Rating | 20A |
| Grade | Federal Specification |
| Horsepower Rating | 1 hp |
| Housing Material | Thermoplastic Nylon |
| Includes Mounting Hardware | Yes |
| Maximum Operating Temperature | 140°F |
| Maximum Wire Size | 10 AWG |
| Minimum Operating Temperature | -40°F |
| Minimum Wire Size | 14 AWG |
| Mount Type | Flush |
| Nema Enclosure Rating | Not Rated |
| Overall Depth | 1.1" |
| Phase | Single |
| Special Resistance | Tamper Resistant |
| Standards | ANSI, CSA CERTIFIED, UL LISTED |
| Voltage Rating | 125V AC |
| Wire Connection Types | Screw Terminals |
| Ship weight (kg) | 0.09 |
| Ship height (cm) | 116.84 |
| Ship length (cm) | 3.33 |
| Ship width (cm) | 2.54 |
| Country of Origin | MX |
