| Item | Union |
| Application | Air |
| Color | Black |
| Fitting Material | Nylon |
| Fitting Side A Connection Type | Push-to-Connect |
| Fitting Side A Tube Outer Diameter | 6 mm |
| Fitting Side B Connection Type | Push-to-Connect |
| Fitting Side B Tube Outer Diameter | 8 mm |
| Includes Pre-applied Thread Sealant | No |
| Maximum Operating Pressure | 290 psi |
| Maximum Operating Temperature | 176°F |
| Minimum Operating Temperature | 4°F |
| Overall Length | 38 mm |
| Release Type | Button |
| Resistance Properties | Chemical Resistant, Corrosion Resistant |
| Specific Fitting Shape | Straight Reducing Connector |
| Standards | 2011/65/EC, DI: 1907/2006 (REACH), DI: 2002/95/EC (ROHS), DI: 97/23/EC (PED), ISO 14743 |
| System Of Measurement | Metric |
| Vacuum Rating | 28 in. hg |
| Ship weight (kg) | 0.05 |
| Ship height (cm) | 5.08 |
| Ship length (cm) | 5.08 |
| Ship width (cm) | 5.08 |
| Country of Origin | FR |
| Model | Basic Material | Body Material | Temp. Range | Tube Size | Pkg. Qty. | Price | |
|---|---|---|---|---|---|---|---|
| 3106 56 00 | Plastic | Glass Filled Nylon | -4 Degrees to 175 Degrees F | 1/4" | 10 | €65.62 | |
| 3106 60 00 | Plastic | Glass Filled Nylon | -4 Degrees to 175 Degrees F | 3/8" | 10 | €99.73 | |
| 3106 04 00 | Plastic | Glass Filled Nylon | -4 Degrees to 175 Degrees F | 5/32" or 4 mm | 10 | €72.71 | |
| 3106 04 06 | - | - | - | - | 10 | €139.29 | |
| 3106 04 56 | - | - | - | - | 10 | €85.26 | |
| 3106 06 00 | Plastic | Glass Filled Nylon | -4 Degrees to 175 Degrees F | 6mm | 10 | €88.03 | |
| 3106 08 00 | Plastic | Glass Filled Nylon | -4 Degrees to 175 Degrees F | 5/16" or 8 mm | 10 | €97.24 |
