| Item | DC Motor |
| Amps | 1.8A |
| Assembly | M1041221 |
| Duty Cycle | Continuous |
| Efficiency | 77.8% |
| Form Factor | 1.38 |
| Frame | 31 |
| Hp | 1/6 hp |
| Insulation Class | Class F |
| Lubrication | Polyrex EM |
| Max. Ambient Temp. | 40°C |
| Motor Enclosure Design | Totally Enclosed Non Ventilated |
| Motor Shaft Rotation | Reversible |
| Mounting Type | C Face, Footless |
| Nameplate Rpm | 1750 RPM |
| Packaging | M1307027.01 |
| Rotation | Reconn |
| Service Factor | 1 |
| Shaft Dia. | 1/2" |
| Torque | 96 oz.-in. |
| Type | DN |
| Voltage | 90V DC |
| Brush Type | External |
| Full Load Current (a) | 1.8A |
| Full Load Torque | 96 oz-in |
| Horsepower | 0.17 hp |
| Maximum Ambient Temperature | 40°C |
| Motor Mounting Type | Square Flange |
| Motor Service Factor | 1 |
| Motor Sub Application | General Purpose |
| Motor Thermal Protection | No Protection |
| Nominal Efficiency | 77.8% |
| Overall Length | 9.45" |
| Rpm Range | 1750 |
| Shaft Diameter | 1/2" |
| Standards | CE, CSA, UL |
| Voltage Compatibility | 115V AC |
| Weight | 11 lbs. |
| Ship weight (kg) | 4.95 |
| Ship height (cm) | 16.99 |
| Ship length (cm) | 41.91 |
| Ship width (cm) | 19.51 |
| Country of Origin | US |
| Product | Model | Amps | Assembly | Enclosure | Frame | HP | Insulation Class | Mounting | Packaging | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
M1110003.00 | 0.7 | M1041047 | TENV | 25 | 1/25 | H | SQ. FLANGE | M1307027.01 | €461.70 | |
 |
M1110015.00 | 0.7 | M1041059 | TENV | 25 | 1/15 | F | SQ. FLANGE | M1307027.01 | €350.91 | RFQ
|
 |
M1120013.00 | .8 | M1041219 | TENV | 31 | 1/15 | F | SQ. FLANGE | M1307027.01 | €363.00 | |
 |
M1120014.00 | 1.1 | M1041215 | TENV | 31 | 1/10 | F | SQ. FLANGE | M1307027.01 | €142.77 | RFQ
|
 |
M1120027.00 | 1.3 | M1041223 | TENV | 31 | 1/8 | H | SQ. FLANGE | M1307027.01 | €446.41 | |
 |
M1120041.00 | 0.55 | M1041225 | TENV | 31 | 1/10 | F | SQ. FLANGE | M1307027.01 | €134.15 | |
 |
M1120059.00 | 1.5 | M1041215 | TENV | 31 | 1/8 | H | SQ. FLANGE | M1307027.01 | €411.56 |
