LEESON LM26359 SSN4S1TC61Q10 Encoder Motor, 1 HP, 3 Phase, 60 Hz, 230/460V, 1800 RPM
€225.71 /unit
Request a Quote
Payment
Payment
| Item | Vector Motor |
| Ambient Temp. | 40°C |
| Code | U |
| Constant Torque | 2000:1 |
| Design | INV, U |
| Duty Cycle | Continuous |
| Frame | 145TC |
| Frequency | 60 Hz |
| Full Load Amps | 4/2A |
| Grease Type | Polyrex EM |
| Hp | 1 hp |
| Insulation Class | Class F |
| Max. Rpm | 1800 RPM |
| Motor Enclosure Design | Totally Enclosed Non Ventilated |
| Motor Shaft Rotation | Clockwise/Counter Clockwise |
| Motor Type | Squirrel Cage Inverter Rated |
| Mounting Type | Rigid Base |
| Packaging | B |
| Phase | 3 |
| Power | 0.75 kW |
| Power Factor | 57.5 |
| Service Factor | 1 |
| Type | TTR |
| Ship weight (kg) | 23.4 |
| Ship height (cm) | 20.62 |
| Ship length (cm) | 41.61 |
| Ship width (cm) | 26.67 |
| Country of Origin | MX |
| Product | Model | Enclosure | Frame | Full Load Amps | HP | Hz | kW | Lubrication | Power Factor | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
LM06125 | TENV | 213TC | 15.6 / 7.8 | 5 | 60 | 3.7 | MULTEMP SRL | 73 | €2,247.72 | |
 |
LM10336 | TEFC | 56C | 1.6 / .8 | 1/3 | 60 | .246 | MULTEMP SRL | 60 | €596.36 | |
 |
LM10339 | TEFC | 56HC | 3 / 1.5 | 3/4 | 50/60 | .56 | MULTEMP SRL | 66.3 / 68 | €775.55 | |
 |
LM10340 | TEFC | 56HC | 3.6 / 1.8 | 1 | 50/60 | .75 | VERIFY | 68.4 / 73 | €1,490.03 |
