LEESON LM10339 SRF4S0.75TC61Q20 Encoder Motor, 0.75 HP, 3 Phase, 60/50 Hz, 230/460 and 200/400V, 1800 and 1500 RPM
Get it by Tuesday, Jun 17
€775.55 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | Vector Motor |
| Ambient Temp. | 40°C |
| Code | L |
| Constant Torque | 2000:1 |
| Design | INV, L |
| Duty Cycle | Continuous |
| Frame | 56HC |
| Frequency | 50/60 Hz |
| Full Load Amps | 3/1.5A |
| Grease Type | Multemp SRL |
| Hp | 3/4 hp |
| Insulation Class | Class F |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Shaft Rotation | Clockwise/Counter Clockwise |
| Motor Type | Squirrel Cage Inverter Rated |
| Mounting Type | Rigid Base |
| Nameplate Rpm | 1800/1500 RPM |
| Packaging | B |
| Phase | 3 |
| Power | 0.56 kW |
| Service Factor | 1 |
| Thermal Protection | Thermostat |
| Type | TS |
| Ship weight (kg) | 11.25 |
| Ship height (cm) | 20.62 |
| Ship length (cm) | 41.61 |
| Ship width (cm) | 26.67 |
| Country of Origin | MX |
