LEESON 5KH39QN9725T 4730 / 5KH39QN9725BT Fan and Blower Motor, 0.25 HP, 1 Phase, 60 Hz, 115V, 1800 RPM
Get it by Tuesday, Jun 17
€242.00 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | HVAC Motor |
| Ambient Temp. | 40°C |
| Duty Cycle | Continuous |
| Enclosure Type | Dripproof |
| Frame | 48Y |
| Frequency | 60 Hz |
| Full Load Amps | 5A |
| Hp | 1/4 hp |
| Insulation Class | Class B |
| Max. Ambient Temp. | 40°C |
| Motor Enclosure Design | Dripproof |
| Motor Mounting Position | All Angle |
| Motor Mounting Type | Resillient Ring |
| Motor Shaft Rotation | CCW |
| Motor Thermal Protection | Automatic |
| Motor Type | Split Phase |
| Nameplate Rpm | 1725 RPM |
| Number Of Speeds | 1 |
| Phase | 1 |
| Service Factor | 1.35 |
| Shaft Dia. | 1/2" |
| Shaft Length | 1 1/2" |
| Shaft Orientation | Horizontal/Vertical |
| Thermal Protection | Automatic |
| Voltage | 115V AC |
| Ship weight (kg) | 5.85 |
| Ship height (cm) | 19.05 |
| Ship length (cm) | 32.08 |
| Ship width (cm) | 17.63 |
| HS code | 8501404040 |
| Country of Origin | MX |
| Product | Model | Full Load Amps | HP | Service Factor | Voltage | Price | |
|---|---|---|---|---|---|---|---|
 |
5KH39QN9696X | 5.8 | 1/3 | 1.35 | 115 | €259.28 | |
 |
5KH39QN9704T | 4.0 | 1/2 | 1.25 | 230 | €114.67 | RFQ
|
