LEESON 5KCR49ZN0785S C1909 General Purpose Farm Duty Motor, 1.50 HP, 1 Phase, 60 Hz, 115/208-230V, 1800 RPM
Get it by Monday, Jun 16
€610.59 /unit
Add To Cart
Request a Quote
Payment
Get it by Monday, Jun 16
Payment
| Item | Poultry Fan Motor |
| Application | Farm Duty |
| Bearing Type | Ball |
| Capacitor Required | Yes |
| Duty Cycle | Continuous |
| Frame | 56 |
| Frame Material | Rolled Steel , Steel |
| Frequency | 50/60 Hz |
| Full Load Amps | 14/7-7.2A |
| Hp | 1 1/2 hp |
| Keyway | 0.188" x 0.188" |
| Length Less Shaft | 12.062" |
| Max. Ambient Temp. | 40°C |
| Motor Application | Poultry Fans |
| Motor Enclosure Design | Totally Enclosed Non Ventilated |
| Motor Mounting Position | All Angle |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Motor Sub Application | Direct Drive Fan/Blower |
| Motor Thermal Protection | Automatic |
| Mounting Type | Cradle Base |
| Nameplate Rpm | 1725.0 |
| Nominal Efficiency | 78.5% |
| Number Of Speeds | 1 |
| Overall Length | 13.938" |
| Phase | 1 |
| Rpm Range | 1701-1800 RPM |
| Service Factor | 1.3 |
| Shaft Dia. | 5/8" |
| Shaft Length | 1 7/8" |
| Shaft Type | Smooth |
| Thermal Protection | Automatic |
| Usable @ 200v | No |
| Usable @ 208v | Yes |
| Voltage | 115/208-230V AC |
| Hz | 60 Hz |
| Ins. Class | Class B |
| Motor Bearings | Ball |
| Motor Design | Capacitor Start/Run |
| Motor Frame Material | Steel |
| Motor Mounting Type | Cradle Base |
| Motor Service Factor | 1.3 |
| No. Of Speeds | 1 |
| Standards | CSA CERTIFIED, UL RECOGNIZED |
| Weight | 49 lbs. |
| Ship weight (kg) | 22.05 |
| Ship height (cm) | 24.13 |
| Ship length (cm) | 38.46 |
| Ship width (cm) | 25.88 |
| HS code | 8501406040 |
| Country of Origin | MX |
| Product | Model | Capacitor Required | Enclosure | Frame | Full Load Amps | HP | Hz | Length Less Shaft | Motor Design | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
5KHC39QN9575T | - | Totally Enclosed Nonventilated | 48 | 3.0/1.6-1.5 | 1/4 | 60 | - | Split-Phase | €126.48 | |
 |
5KH49MN6057S | No | Totally Enclosed Nonventilated | 56 | 5.6 | 1/4 | 60 | - | Split-Phase | €481.96 | |
 |
5KH33JNA500S | No | Totally Enclosed Nonventilated | 48Z | 6.2 | 1/3 | 60 | - | Split-Phase | €252.12 | |
 |
5KH42JN0328S | No | Totally Enclosed Nonventilated | 56 | 8.0/4.0-4.0 | 1/2 | 60 | - | Split-Phase | €337.32 | |
 |
5KCP36NNB059S | No | Totally Enclosed Nonventilated | 48Z | 7.2/3.6 | 1/2 | 60 | 8.5" | Permanent Split Capacitor | €259.29 | |
 |
5KCR49SN0493S | Yes | Totally Enclosed Nonventilated | 56 | 10.6/5.5-5.3 | 1 | 60 | - | Capacitor-Start/Run | €514.81 | |
 |
5KH32FNA499S | - | Totally Enclosed Air-Over | 48Z | 5.1 | 1/4 | 60 | 7.437" | Split-Phase | €220.11 |
