LEESON 5KC49NN2167X C337 General Purpose Pump Motor, 1.50 HP, 1 Phase, 60 Hz, 115/230V, 3600 RPM
Get it by Wednesday, Jun 18
€759.95 /unit
Add To Cart
Request a Quote
Payment
Get it by Wednesday, Jun 18
Payment
| Item | Jet Pump Motor |
| Amps | 18.4/9.2A |
| Bearing Type | Ball |
| Body Dia. | 6 2/5" |
| Bolt Circle Dia. | 2.938" |
| Duty Cycle | Continuous |
| Frame | 56J |
| Frame Material | Steel |
| Frequency | 60 Hz |
| Hp | 1 1/2 hp |
| Includes | Shaft Slinger |
| Insulation Class | Class B |
| Length Less Shaft | 9 1/2" |
| Max. Ambient Temp. | 40°C |
| Motor Application | Pump |
| Motor Enclosure Design | Open Dripproof |
| Motor Mounting Position | All Angle |
| Motor Shaft Rotation | CCW |
| Motor Type | Capacitor Start/Induction Run |
| Mounting Position | Horizontal/Vertical |
| Mounting Type | Face |
| Nameplate Rpm | 3450 RPM |
| Nema Design | L |
| Nominal Efficiency | 72% |
| Number Of Speeds | 1 |
| Overall Length | 11 7/8" |
| Phase | 1 |
| Rpm Range | 3001-3600 RPM |
| Service Factor | 1.3 |
| Shaft Dia. | 5/8" |
| Shaft Length | 2 3/8" |
| Shaft Material | Stainless Steel |
| Shaft Type | Threaded |
| Thermal Protection | Automatic |
| Usable @ 200v | No |
| Usable @ 208v | No |
| Voltage | 115/230V AC |
| Full Load Amps | 18.4/9.2A |
| Hz | 60 Hz |
| Ins. Class | Class B |
| Motor Bearings | Ball |
| Motor Design | Capacitor Start |
| Motor Frame Material | Steel |
| Motor Mounting Type | Face |
| Motor Service Factor | 1.3 |
| Motor Shaft Design | Threaded |
| Motor Thermal Protection | Auto |
| No. Of Speeds | 1 |
| Standards | CSA, UL RECOGNIZED |
| Weight | 26 lbs. |
| Ship weight (kg) | 11.7 |
| Ship height (cm) | 19.05 |
| Ship length (cm) | 34.77 |
| Ship width (cm) | 18.11 |
| HS code | 8501406040 |
| Country of Origin | MX |
| Product | Model | Body Dia. | Enclosure | Full Load Amps | HP | Item | Motor Mounting Position | Overall Length | Rotation | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
5KC36JN269X | 5.66" | Open Dripproof | 3.7-3.8 | 1/2 | Jet Pump Motor | Horizontal | 10.875" | CCWSE | €293.24 | |
 |
5KC39QN3219X | 5.66" | Open Dripproof | 5.3-5.6 | 3/4 | Jet Pump Motor | Horizontal | 12.375" | CCWSE | €339.54 | |
 |
5KC39RN45X | 5.66" | Open Dripproof | 6.5/6.6 | 1 | Jet Pump Motor | Horizontal | 13.125" | CCWSE | €379.06 | |
 |
5KCR48TN2174T | 6.42" | Open Dripproof | 29.4/14.7 | 3 | Jet Pump Motor | All Angle | 13.187" | CCWSE | €1,040.24 | |
 |
5KC37FN65X | - | DP | 6.4/3.0-3.2 | 1/3 | Pump Motor | - | - | Clockwise | €266.07 |
