LEESON 5KC39RN45X C335 / 5KC39RN45HX General Purpose Pump Motor, 1 HP, 1 Phase, 60 Hz, 115/208-230V, 3600 RPM
Get it by Tuesday, Jun 17
€379.06 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | Jet Pump Motor |
| Amps | 6.5/6.6A |
| Bearing Type | Ball |
| Body Dia. | 5 3/5" |
| Bolt Circle Dia. | 2.938" |
| Cc Number | CC003A |
| Conduit Box Location | Exterior |
| Duty Cycle | Continuous |
| Frame | 56J |
| Frame Material | Steel |
| Frequency | 60 Hz |
| Full Load Amps | 13.2/6.6-6.5A |
| Hp | 1 hp |
| Includes | Shaft Slinger |
| Length Less Shaft | 10 3/4" |
| Max. Ambient Temp. | 40°C |
| Motor Application | Pump |
| Motor Enclosure Design | Open Dripproof |
| Motor Mounting Position | All Angle |
| Motor Shaft Design | Threaded |
| Motor Shaft Rotation | CCWSE |
| Motor Thermal Protection | Automatic |
| Motor Type | Capacitor Start Induction Run |
| Mounting Type | Face |
| Nameplate Rpm | 3450 RPM |
| Nominal Efficiency | 68.1% |
| Number Of Speeds | 1 |
| Overall Length | 13 1/8" |
| Phase | 1 |
| Rpm Range | 3001-3600 RPM |
| Service Factor | 1.4 |
| Shaft Dia. | 5/8" |
| Shaft Length | 2 3/8" |
| Shaft Material | Stainless Steel |
| Shaft Type | Threaded |
| Thermal Protection | Automatic |
| Usable @ 200v | No |
| Usable @ 208v | Yes |
| Voltage | 115/208-230V AC |
| Hz | 60 Hz |
| Ins. Class | Class B |
| Motor Bearings | Ball |
| Motor Design | Capacitor Start |
| Motor Frame Material | Steel |
| Motor Mounting Type | Face |
| Motor Service Factor | 1.4 |
| No. Of Speeds | 1 |
| Standards | CSA CERTIFIED, UL RECOGNIZED |
| Weight | 22 lbs. |
| Ship weight (kg) | 9.9 |
| Ship height (cm) | 19.05 |
| Ship length (cm) | 39.7 |
| Ship width (cm) | 25.1 |
| HS code | 8501406040 |
| Country of Origin | MX |
| Product | Model | Body Dia. | Enclosure | Full Load Amps | HP | Item | Motor Mounting Position | Overall Length | Rotation | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
5KC36JN269X | 5.66" | Open Dripproof | 3.7-3.8 | 1/2 | Jet Pump Motor | Horizontal | 10.875" | CCWSE | €293.24 | |
 |
5KC39QN3219X | 5.66" | Open Dripproof | 5.3-5.6 | 3/4 | Jet Pump Motor | Horizontal | 12.375" | CCWSE | €339.54 | |
 |
5KC49NN2167X | 6.42" | Open Dripproof | 18.4/9.2 | 1.5 | Jet Pump Motor | All Angle | 11.875" | CCWSE | €759.95 | |
 |
5KCR48TN2174T | 6.42" | Open Dripproof | 29.4/14.7 | 3 | Jet Pump Motor | All Angle | 13.187" | CCWSE | €1,040.24 | |
 |
5KC37FN65X | - | DP | 6.4/3.0-3.2 | 1/3 | Pump Motor | - | - | Clockwise | €266.07 |
