| Item | Washdown Motor |
| Code | L |
| Design | B |
| Duty | Continuous |
| Enclosure | TENV |
| Frame | 56C |
| Full Load Amps | 3.8 / 1.9 |
| HP | 1.5 |
| Hz | 60 |
| Insulation Class | F |
| kW | 1.12 |
| Lubrication | Polyrex EM |
| Max. Ambient Temp. | 40 |
| Mounting | Round |
| Packaging | B |
| Phase | 3 |
| Power Factor | 88 |
| Rotation | REV |
| RPM | 3600 |
| Service Factor | 1.15 |
| Shaft Dia. | 5/8" |
| Type | TN |
| Voltage | 230 / 460 |
| Ship weight (kg) | 20.25 |
| Ship height (cm) | 27.64 |
| Ship length (cm) | 36.68 |
| Ship width (cm) | 26.52 |
| Product | Model | Shaft Dia. | Motor Thermal Protection | Enclosure | Full Load Amps | HP | Hz | kW | Max. Ambient Temp. | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
113019.00 | 5/8" | - | TENV | 2.7-2.5 / 1.25 | 3/4 | 60 | .56 | 40 | €1,141.47 | |
 |
113022.00 | 5/8" | - | TENV | 2.6-2.4 / 1.2 | 3/4 | 60 | .56 | 40 | €906.61 | |
 |
113023.00 | 5/8" | - | TENV | 2.6 / 1.3 | 1 | 60 | .75 | 40 | €1,035.51 | |
 |
113473.00 | 5/8" | - | TENV | 2.0-1.8 / .9 | 1/2 | 60 | .37 | 40 | €977.72 | |
 |
113649.00 | 5/8" | - | TENV | 1.1 / .55 | 1/4 | 60 | .187 | 40 | €891.04 | |
 |
116644.00 | 5/8" | - | TEFC | 2 / 1 | 1/2 / 1/3 | 50/60 | 0.37 / 0.25 | 40 | €977.72 | |
 |
116645.00 | 5/8" | - | TEFC | 2.7-2.8 / 1.4 | 3/4 / 1/2 | 50/60 | 0.56 / 0.37 | 40 | €1,064.29 |
