LEESON 056T34F99018 56T34F99018A / J064A Jet Pump Motor, 1.50/1 HP, 3 Phase, 60/50 Hz, 208-230/460 and 190/380V, 3600 and 3000 RPM
Get it by Tuesday, Jun 17
€716.75 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | Jet Pump Motor |
| Amps | 4/2A |
| Bearing Type | Ball |
| Body Dia. | 6 1/2" , 7 2/5" |
| Bolt Circle Dia. | 5 7/8" |
| Cc Number | CC003A |
| Conduit Box Location | Exterior |
| Conduit Box Position | F1 Only |
| Duty Cycle | Continuous |
| Efficiency | 85.5% |
| Efficiency Group | NEMA Premium |
| Frame | 56J |
| Frame Material | Steel |
| Frequency | 50/60 Hz |
| Full Load Amps | 4.2-4/2A |
| Hp | 1 1/2 hp |
| Includes | Drip Cover |
| Length Less Shaft | 11 1/4" |
| Max. Ambient Temp. | 40°C |
| Motor Application | Jet Pump |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Mounting Position | Horizontal |
| Motor Shaft Design | Threaded |
| Motor Shaft Rotation | CW/CCW |
| Motor Sub Application | Jet Pump |
| Motor Thermal Protection | No |
| Motor Type | Three Phase |
| Mounting Type | Face, Base |
| Nameplate Rpm | 3450 RPM |
| Nema Design | B |
| Nominal Efficiency | 85.5% |
| Number Of Speeds | 1 |
| Overall Length | 13 13/16" |
| Phase | 3 |
| Rpm Range | 3001-3600 RPM |
| Service Factor | 1.15 |
| Shaft Dia. | 5/8" |
| Shaft Length | 2 3/8" |
| Shaft Material | Stainless Steel |
| Shaft Type | Threaded |
| Thermal Protection | None |
| Usable @ 200v | No |
| Usable @ 208v | Yes |
| Voltage | 208-230/460V AC |
| Hz | 50/60 Hz |
| Ins. Class | Class B |
| Motor Bearings | Ball |
| Motor Design | 3-Phase |
| Motor Frame Material | Steel |
| Motor Mounting Type | Face/Base |
| Motor Service Factor | 1.15 |
| No. Of Speeds | 1 |
| Standards | CE MARK, CSA CERTIFIED, UL RECOGNIZED |
| Weight | 39 lbs. |
| Ship weight (kg) | 17.37 |
| Ship height (cm) | 24.77 |
| Ship length (cm) | 48.26 |
| Ship width (cm) | 27.64 |
| HS code | 8501524000 |
| Country of Origin | MX |
| Product | Model | Full Load Amps | HP | Hz | Item | Voltage | Price | |
|---|---|---|---|---|---|---|---|---|
 |
056T34F5343 | 3-3.2/1.6 | 3/4 | 60 | Pump Motor | 208-230/460 | €479.68 | |
 |
056T34F99029 | - | 1 | 60 | Jet Pump Motor | 208-230/460 | €578.46 |
