LEESON 056T34F5343 J062 / 56T34F5343D General Purpose Pump Motor, 0.75/0.50 HP, 3 Phase, 60/50 Hz, 208-230/460V, 3600 RPM
Get it by Tuesday, Jun 17
€479.68 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | Pump Motor |
| Amps | 3-3.2/1.6A |
| Assembly | F1 Only |
| Bearing Type | Ball |
| Body Dia. | 7 2/5" |
| Bolt Circle Dia. | 5 7/8" |
| Conduit Box Location | Exterior |
| Conduit Box Position | F1 Only |
| Design | B |
| Duty Cycle | Continuous |
| Efficiency | 74% |
| Frame | 56J |
| Frame Material | Steel |
| Frequency | 50/60 Hz |
| Full Load Amps | 3-3.2/1.6A |
| Hp | 3/4 hp |
| Includes | Drip Cover |
| Length Less Shaft | 10.062" |
| Max. Ambient Temp. | 40°C |
| Motor Application | Pump |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Mounting Position | Horizontal |
| Motor Shaft Design | Threaded |
| Motor Shaft Rotation | CW/CCW |
| Motor Thermal Protection | No |
| Motor Type | Squirrel Cage Induction Run |
| Mounting Type | C Face, Rigid Base , Face, Base |
| Nameplate Rpm | 3600 RPM |
| Nema Design | B |
| Nominal Efficiency | 74% |
| Number Of Speeds | 1 |
| Orientation | Horizontal |
| Overall Length | 12.312" |
| Phase | 3 |
| Power | 0.56 kW |
| Service Factor | 1.15 |
| Shaft Dia. | 5/8" |
| Shaft Length | 2 5/8" |
| Shaft Material | Stainless Steel |
| Usable @ 200v | No |
| Usable @ 208v | Yes |
| Voltage | 208-230/460V AC |
| Hz | 50/60 Hz |
| Ins. Class | Class B |
| Motor Bearings | Ball |
| Motor Design | 3-Phase |
| Motor Frame Material | Steel |
| Motor Mounting Type | Face/Base |
| Motor Service Factor | 1.15 |
| No. Of Speeds | 1 |
| Standards | CE MARK, CSA CERTIFIED, UL RECOGNIZED |
| Weight | 26 lbs. |
| Ship weight (kg) | 11.7 |
| Ship height (cm) | 20.62 |
| Ship length (cm) | 41.61 |
| Ship width (cm) | 26.67 |
| HS code | 8501514040 |
| Country of Origin | MX |
| Product | Model | Full Load Amps | HP | Hz | Item | Voltage | Price | |
|---|---|---|---|---|---|---|---|---|
 |
056T34F99029 | - | 1 | 60 | Jet Pump Motor | 208-230/460 | €578.46 | |
 |
056T34F99018 | 4.0/2.0 | 1.5 | 50/60 | Jet Pump Motor | 230/460 | €716.75 |
