LEESON 056T11O5300 X500 / 56T11O5300H Condenser Fan Motor, 0.50/0.33 HP, 3 Ph, 60/50 Hz, 200-230/460 and 190/380V, 1200 RPM
Get it by Tuesday, Jun 17
€762.43 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | HVAC Motor |
| Ambient Temp. | 70°C |
| Assembly | F1 Only |
| Duty Cycle | Continuous |
| Efficiency | 68% |
| Enclosure Type | Open Air Over |
| Full Load Amps | 2.4-2.7/1.35A |
| Hp | 1/2 hp |
| Insulation Class | Class H |
| Mounting Type | Belly Band Footless |
| Nema Design | No Design Code |
| Phase | 3 |
| Power | 0.37 kW |
| Service Factor | 1 |
| Shaft Orientation | Horizontal |
| Thermal Protection | Automatic |
| Voltage | 200-230/460V AC |
| Ship weight (kg) | 9 |
| Ship height (cm) | 20.62 |
| Ship length (cm) | 41.61 |
| Ship width (cm) | 26.67 |
| HS code | 8501514040 |
| Country of Origin | MX |
| Product | Model | Duty | Enclosure | Frame | Full Load Amps | HP | Insulation Class | kW | NEMA Design | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
056T11O5303 | CONTINUOUS AOM | OPAO | 56Z | 5.5-5.4/2.7 | 1.5 | H | 1.12 | NO DESIGN CODE | €568.32 | |
 |
056T11O5302 | CONTINUOUS AOM | OPAO | 56Z | 4-4.2/2.1 | 1 | H | 0.75 | NO DESIGN CODE | €521.89 | |
 |
056T8O5307 | CONTINUOUS AOM | OPAO | 56Y | 7.5-6.8/3.4 | 1.5 | H | 1.12 | B | €1,129.75 | |
 |
056T11O5304 | CONTINUOUSAOM | OPAO | 56Y | 7.2-6.8/3.4 | 2 | H | 1.49 | NO DESIGN CODE | €616.60 | |
 |
5K49RN6429S | Continuous | DP | 56Z | 1.6 | 1 | B | - | - | €705.63 | |
 |
056T8O5302 | CONTINUOUSAOM | OPAO | 56Y | 5.3-5.3/2.65 | 1 | H | 0.75 | NO DESIGN CODE | €984.05 | |
 |
5K38SN267S | Continuous | Open | 48Z | 3.3-3.8/1.9 | 3/4 | B | - | B | €138.51 |
