LEESON 056C17F5308 G356 / 56C17F5308H General Purpose Motor, 0.75 HP, 1 Phase, 60 Hz, 115/208-230V, 1800 RPM
Get it by Friday, Jun 13
€630.30 /unit
Add To Cart
Request a Quote
Payment
Get it by Friday, Jun 13
Payment
| Item | Definite Purpose Motor |
| Ambient Temp. | 40°C |
| Assembly | F1 Only |
| Base Type | Rigid Base |
| Bearing Type | Ball |
| Conduit Box Position | F1 Only |
| Duty Cycle | Continuous |
| Efficiency | 70% |
| Frame | 56 |
| Frame Material | Steel |
| Frequency | 60 Hz |
| Full Load Amps | 11/5.4-5.5A |
| Hp | 3/4 hp |
| Insulation Class | Class B |
| Inverter Rated | No |
| Length Less Shaft | 10" |
| Max. Ambient Temp. | 104°F |
| Motor Application | General Application |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Mounting Position | Horizontal |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Motor Type | Capacitor Start |
| Mounting | Rigid Base |
| Mounting Type | Rigid Base |
| Nameplate Rpm | 1800 RPM |
| Nema Design | N |
| Nominal Efficiency | 70% |
| Number Of Speeds | 1 |
| Orientation | Horizontal |
| Overall Length | 12 5/16" |
| Phase | 1 |
| Power | 0.56 kW |
| Rpm Range | 1701-1800 RPM |
| Service Factor | 1.15 |
| Shaft Dia. | 5/8" |
| Shaft Length | 2 5/16" |
| Thermal Protection | Manual |
| Usable @ 200v | No |
| Usable @ 208v | Yes |
| Voltage | 115/208-230V AC |
| Warranty | 1 yr. |
| Hz | 60 Hz |
| Ins. Class | Class B |
| Manufacturers Warranty Length | 1 yr. |
| Motor Bearings | Ball |
| Motor Design | Capacitor Start |
| Motor Frame Material | Steel |
| Motor Mounting Type | Rigid Base |
| Motor Service Factor | 1.15 |
| Motor Thermal Protection | Manual |
| No. Of Speeds | 1 |
| Standards | CE, CSA, UL RECOGNIZED |
| Weight | 29 lbs. |
| Ship weight (kg) | 13.05 |
| Ship height (cm) | 23.16 |
| Ship length (cm) | 40.94 |
| Ship width (cm) | 26.04 |
| HS code | 8501404040 |
| Country of Origin | MX |
| Product | Model | Assembly | Frame | Full Load Amps | HP | kW | NEMA Design | RPM | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
 |
056C17F5311 | F1 ONLY | 56 | 13.4/6.8-6.7 | 1 | 0.75 | N | 1800 | €659.95 | |
 |
056B17F5302 | F1 ONLY | 56H | 15.2/8.2-7.6 | 1.5 | 1.12 | N | 1800 | €756.87 | |
 |
056B34F5303 | F3 | 56 | 12.1/6.9-6 | 1.5 | 1.12 | B | 3600 | €201.90 |
