LEESON 056B34F5303 K332 / 56B34F5303I Pressure Washer Motor, 1.50 HP, 1 Phase, 60 Hz, 115/208-230V, 3600 RPM
Get it by Tuesday, Jun 17
€201.90 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | Definite Purpose Motor |
| Ambient Temp. | 40°C |
| Bearing Type | Ball |
| Body Dia. | 7 2/5" |
| Conduit Box Location | Exterior |
| Conduit Box Position | F3 |
| Design | L |
| Duty Cycle | Continuous |
| Frame | 56 |
| Frame Material | Steel |
| Frequency | 60 Hz |
| Full Load Amps | 12.1/6-6.9A |
| Hp | 1 1/2 hp |
| Insulation Class | Class B |
| Length Less Shaft | 13" |
| Motor Application | Pressure Washer |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Mounting Position | Horizontal |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Mounting Type | Rigid Base |
| Nameplate Rpm | 3450 RPM |
| Nominal Efficiency | 77% |
| Number Of Speeds | 1 |
| Overall Height | 8.812" |
| Overall Length | 13.312" |
| Phase | 1 |
| Power | 1.12 kW |
| Service Factor | 1.15 |
| Shaft Dia. | 5/8" |
| Shaft Length | 2 3/8" |
| Thermal Protection | Manual |
| Usable @ 200v | No |
| Usable @ 208v | Yes |
| Voltage | 115/208-230V AC |
| Ship weight (kg) | 16.65 |
| Ship height (cm) | 23.83 |
| Ship length (cm) | 39.37 |
| Ship width (cm) | 31.12 |
| HS code | 8501406040 |
| Country of Origin | MX |
| Product | Model | Assembly | Frame | Full Load Amps | HP | kW | NEMA Design | RPM | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
 |
056C17F5311 | F1 ONLY | 56 | 13.4/6.8-6.7 | 1 | 0.75 | N | 1800 | €659.95 | |
 |
056C17F5308 | F1 ONLY | 56 | 11/5.4-5.5 | 3/4 | 0.56 | N | 1800 | €630.30 | |
 |
056B17F5302 | F1 ONLY | 56H | 15.2/8.2-7.6 | 1.5 | 1.12 | N | 1800 | €756.87 |
