LEESON 056C17D2073 B318 / 56C17D2073P General Purpose Motor, 0.75 HP, 1 Phase, 60 Hz, 115/230V, 1800 RPM
Get it by Tuesday, Jun 17
€556.22 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | HVAC Motor |
| Ambient Temp. | 40°C |
| Bearing Type | Ball |
| Conduit Box Position | F1 Only |
| Duty Cycle | Continuous |
| Efficiency | 70.1% |
| Enclosure Type | Dripproof |
| Frame | 56 |
| Frame Material | Steel |
| Frequency | 60 Hz |
| Full Load Amps | 10/5-5.2A |
| Hp | 3/4 hp |
| Insulation Class | Class B |
| Inverter Rated | No |
| Length Less Shaft | 8 13/16" |
| Max. Ambient Temp. | 104°F |
| Motor Application | General Application |
| Motor Enclosure Design | Open Dripproof |
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Cradle Base |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Motor Type | Capacitor Start |
| Mounting Type | Resilient Base Extended Studs |
| Nema Design | No Design Code |
| Number Of Speeds | 1 |
| Overall Length | 10 3/4" |
| Phase | 1 |
| Power | 0.56 kW |
| Rpm | 1800 RPM |
| Rpm Range | 1701-1800 RPM |
| Service Factor | 1.25 |
| Shaft Dia. | 5/8" |
| Shaft Length | 1 7/8" |
| Shaft Orientation | Horizontal |
| Thermal Protection | None |
| Usable @ 200v | No |
| Usable @ 208v | Yes |
| Voltage | 115/208-230V AC |
| Warranty | 1 yr. |
| Hz | 60 Hz |
| Ins. Class | Class B |
| Manufacturers Warranty Length | 1 yr. |
| Motor Bearings | Ball |
| Motor Design | Capacitor Start |
| Motor Frame Material | Steel |
| Motor Service Factor | 1.25 |
| Motor Thermal Protection | None |
| Nameplate Rpm | 1725 RPM |
| No. Of Speeds | 1 |
| Nominal Efficiency | 70.1% |
| Standards | CSA, UL RECOGNIZED |
| Weight | 24 lbs. |
| Ship weight (kg) | 10.8 |
| Ship height (cm) | 19.69 |
| Ship length (cm) | 33.66 |
| Ship width (cm) | 20.32 |
| HS code | 8501404040 |
| Country of Origin | MX |
| Product | Model | Frame | Full Load Amps | HP | Hz | kW | Length Less Shaft | Motor Thermal Protection | Mounting | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
5KCR48TN3084X | 56H | 5.3-5.4/3.6-3.7 | 1, 1/3 | 50/60 | - | 10 11/16" | Auto | Cradle Base | €1,009.98 | |
 |
5KCR49PN3011 | 56 | 9.0/6.4 | 3/4, 1/4 | 60 | - | 9.625" | Auto | Cradle Base | €764.89 | |
 |
5KCR49PN3011X | 56 | 9.0/6.4 | 3/4, 1/4 | 60 | - | 9.625" | None | Cradle Base | €898.24 | |
 |
5KCR49PN3012X | 56 | 4.3-4.4/3.1-3.2 | 3/4, 1/4 | 60 | - | 9.625" | Auto | Cradle Base | €777.23 | |
 |
5KCR49SN3009 | 56 | 10.8/7.4 | 1, 1/3 | 60 | - | 10.125" | None | Cradle Base | €951.96 | |
 |
5KCR49SN3009X | 56 | 10.8/7.4 | 1, 1/3 | 60 | - | 10.125" | Auto | Cradle Base | €990.85 | |
 |
056C17D2074 | 56 | 10.0/5.2-5.0 | 3/4 | 60 | 0.56 | - | - | Resilient Base - Extended Studs | €399.76 |
