MARATHON MOTORS 048C17D2041 B312 HVAC Motor | AJ2NAQ B312

LEESON 048C17D2041 B312 / 48C17D2041L Fan and Blower Motor, 0.25 HP, 1 Phase, 60 Hz, 115/208-230V, 1800 RPM

Item: AJ2NAQModel: 048C17D2041Cross Ref: B312 / 48C17D2041L
See variants (23)
In Stock

Get it by Tuesday, Jun 17

€319.78 /unit
Add To Cart
Request a Quote

Payment

Product Specifications:

ItemHVAC Motor
Ambient Temp.40°C
AssemblyF1 Only
Conduit Box PositionF1 Only
Duty CycleContinuous
EfficiencyNot Applicable
Enclosure TypeDripproof
Frame48Z
Frequency60 Hz
Full Load Amps6.2/2.8-3.1A
Hp1/4 hp
Insulation ClassClass B
Max. Ambient Temp.40°C
Motor Enclosure DesignDripproof
Motor Mounting PositionHorizontal
Motor Mounting TypeExtended Studs, Resilient Base
Motor Shaft RotationSelective CCW
Motor Thermal ProtectionNo
Motor TypeCapacitor Start/Induction Run
Mounting TypeResilient Base Extended Studs
Nameplate Rpm1800 RPM
Nema DesignDefinite Duty
Number Of Speeds1
Phase1
Power0.19 kW
Service Factor1.35
Shaft Dia.1/2"
Shaft Length1 22/25"
Shaft OrientationHorizontal
Voltage115/208-230V

Shipping Info:

Ship weight (kg) 6.75
Ship height (cm)20.47
Ship length (cm)31.6
Ship width (cm)23.19
HS code8501404040
Country of OriginMX

Product Details:

    • Starting Type: CAP START IND RUN
    • KVA Code: L
    • Drive End Bearing: BALL
    • IP Code: 12
    • Opposite End Bearing: BALL
    • Drive End Bearing Size: 6203
    • Opposite End Bearing Size: 6203

Product Variants

ProductModelFrameFull Load AmpsHPHzkWLength Less ShaftMotor Thermal ProtectionMountingPrice
MARATHON MOTORS 5KCR48TN3084X Motor 1 1/3 Hp 1725/1140 Rpm 208-230v | AD6NYC 46N398 / C1479 5KCR48TN3084X56H5.3-5.4/3.6-3.71, 1/350/60-10 11/16"AutoCradle Base€1,009.98
MARATHON MOTORS 5KCR49PN3011 Motor 3/4 1/4 Hp 1725/1140 Rpm 115v Auto | AD6NYD 46N399 / C420 5KCR49PN3011569.0/6.43/4, 1/460-9.625"AutoCradle Base€764.89
MARATHON MOTORS 5KCR49PN3011X Motor 3/4 1/4 Hp 1725/1140 Rpm 115v None | AD6NYE 46N401 / C474 5KCR49PN3011X569.0/6.43/4, 1/460-9.625"NoneCradle Base€898.24
MARATHON MOTORS 5KCR49PN3012X Motor 3/4 1/4 Hp 1725/1140 Rpm 208-230v | AD6NYF 113672.00 5KCR49PN3012X564.3-4.4/3.1-3.23/4, 1/460-9.625"AutoCradle Base€777.23
MARATHON MOTORS 5KCR49SN3009 Motor 1 1/3 Hp 1725/1140 Rpm 115v None | AD6NYJ 46N405 / C475 5KCR49SN30095610.8/7.41, 1/360-10.125"NoneCradle Base€951.96
MARATHON MOTORS 5KCR49SN3009X Motor 1 1/3 Hp 1725/1140 Rpm 115v Auto | AD6NYK 46N406 / C1478 5KCR49SN3009X5610.8/7.41, 1/360-10.125"AutoCradle Base€990.85
MARATHON MOTORS 056C17D2074 B319 Single Phase Motor | AJ2KVC 46N371 / B319 056C17D20745610.0/5.2-5.03/4600.56--Resilient Base - Extended Studs€399.76
