LEESON 048A8O183 X209 / 48A8O183K Fan and Blower Motor, 0.33 HP, 1 Phase, 60 Hz, 230V, 900 RPM
Get it by Tuesday, Jun 17
€87.40 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | HVAC Motor |
| Ambient Temp. | 40°C |
| Bearing Type | Ball |
| Body Dia. | 5.688" |
| Bolt Circle Dia. | 5 1/8" |
| Capacitor Included | No |
| Capacitor Required | 2MDV4 |
| Conduit Box Location | Exterior |
| Conduit Box Position | F1 Only |
| Diameter | 5 11/16" |
| Duty Cycle | Continuous |
| Efficiency | 54.4% |
| Enclosure Type | Open Air Over |
| Frame | 48Y |
| Frequency | 60 Hz |
| Full Load Amps | 2.8A |
| Full Load Efficiency | 58% |
| Hp | 1/3 hp |
| Insulation Class | Class B |
| Lead Length | 30" |
| Length | 12 1/4" |
| Length Less Shaft | 6.688" |
| Motor Application | HVAC/R |
| Motor Frame Material | Steel |
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Cushion Ring |
| Motor Shaft Rotation | CW/CCW |
| Motor Sub Application | Direct Drive Fan/Blower |
| Motor Type | Permanent Split Capacitor |
| Mounting Stud Length | 1 1/16", 1 1/4" |
| Mounting Stud Size | 11/64" |
| Mounting Type | Ring |
| No. Of Speeds | 1 |
| Number Of Shafts | 1 |
| Overall Length | 12 1/4" |
| Phase | 1 |
| Ring Dia. | 2 1/2" |
| Ring To Ring Center | 6 3/8" |
| Rpm | 825 RPM |
| Rpm Range | 0-1000 RPM |
| Service Factor | 1 |
| Shaft Dia. | 1/2" |
| Shaft Length | 5 1/2" |
| Shaft Type | Flat |
| Stud Location | Both Ends |
| Stud Pattern | 5 1/8" |
| Stud Size | #8-32 |
| Thermal Protection | Automatic |
| Usable @ 200v | No |
| Usable @ 208v | No |
| Voltage | 230V AC |
| Warranty | 1 yr. |
| Hz | 60 Hz |
| Ins. Class | Class B |
| Manufacturers Warranty Length | 1 yr. |
| Max. Ambient Temp. | 40°C |
| Motor Bearings | Ball |
| Motor Design | Permanent Split Capacitor |
| Motor Enclosure Design | Open Air Over |
| Motor Service Factor | 1 |
| Motor Shaft Design | Flat |
| Motor Thermal Protection | Auto |
| Mounting Stud Location | Both Ends |
| Nameplate Rpm | 825 RPM |
| Nominal Efficiency | 0.58% |
| Resilient Ring Dia. | 2 1/4" |
| Standards | CSA (LR2025), UL (E6312) |
| Weight | 17 lbs. |
| Ship weight (kg) | 7.65 |
| Ship height (cm) | 17.63 |
| Ship length (cm) | 33.66 |
| Ship width (cm) | 17.78 |
| HS code | 8501404040 |
| Country of Origin | MX |
| Product | Model | Capacitor Required | Duty | Enclosure | Frame | Full Load Amps | HP | kW | Length Less Shaft | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
048A11O1674 | 2MDV7 | Continuous | - | 48Y | 6.1 | 1/2 | - | 5" | €240.15 | |
 |
048A11O787 | - | CONTINUOUS AOM | OPAO | 48Z | 10.2 | 3/4 | 0.56 | - | €322.87 | |
 |
048A11O1755 | - | CONTINUOUSAOM | OPAO | 48Y | 6.2 | 1/2 | 0.37 | - | €194.59 | |
 |
048A11O1769 | - | CONTINUOUS AOM | OPAO | 48Z | 4.6 | 1/3 | 0.246 | - | €245.08 | |
 |
048A17O153 | - | CONTINUOUS AOM | OPAO | 48Z | 7.4 | 1/2 | 0.37 | - | €283.37 | |
 |
048A11O2046 | - | CONTINUOUS AOM | OPAO | 48Z | 5.8-5.6 | 3/4 | 0.56 | - | €328.43 | |
 |
048A11O1351 | - | CONTINUOUSAOM | OPAO | 48Y | 2.7 | 1/3 | 0.25 | - | €262.38 |
