LEESON 048A11O787 X009 / 48A11O787J Fan and Blower Motor, 0.75 HP, 1 Phase, 60 Hz, 115V, 1200 RPM
Get it by Wednesday, Jun 18
€322.87 /unit
Add To Cart
Request a Quote
Payment
Get it by Wednesday, Jun 18
Payment
| Item | HVAC Motor |
| Ambient Temp. | 40°C |
| Conduit Box Position | F1 Only |
| Design | L |
| Duty Cycle | Continuous |
| Efficiency | 64% |
| Enclosure Type | Open Air Over |
| Frame | 48Z |
| Frequency | 60 Hz |
| Full Load Amps | 10.2A |
| Hp | 3/4 hp |
| Insulation Class | Class B |
| Motor Mounting Position | Horizontal |
| Motor Shaft Rotation | Selective CCW |
| Motor Type | Permanent Split Capacitor |
| Mounting Type | Resilient Ring Extended Studs |
| Number Of Speeds | 3 |
| Phase | 1 |
| Power | 0.56 kW |
| Rpm | 1075 RPM |
| Service Factor | None |
| Shaft Dia. | 1/2" |
| Shaft Length | 4.06" |
| Shaft Orientation | Horizontal |
| Thermal Protection | Automatic |
| Voltage | 115V AC |
| Ship weight (kg) | 9 |
| Ship height (cm) | 17.63 |
| Ship length (cm) | 33.66 |
| Ship width (cm) | 17.78 |
| HS code | 8501404040 |
| Country of Origin | MX |
| Product | Model | Capacitor Required | Duty | Enclosure | Frame | Full Load Amps | HP | kW | Length Less Shaft | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
048A11O1674 | 2MDV7 | Continuous | - | 48Y | 6.1 | 1/2 | - | 5" | €240.15 | |
 |
048A8O183 | 2MDV4 | Continuous | - | 48Y | 2.8 | 1/3 | - | 6 11/16" | €87.40 | |
 |
048A11O1755 | - | CONTINUOUSAOM | OPAO | 48Y | 6.2 | 1/2 | 0.37 | - | €194.59 | |
 |
048A11O1769 | - | CONTINUOUS AOM | OPAO | 48Z | 4.6 | 1/3 | 0.246 | - | €245.08 | |
 |
048A17O153 | - | CONTINUOUS AOM | OPAO | 48Z | 7.4 | 1/2 | 0.37 | - | €283.37 | |
 |
048A11O2046 | - | CONTINUOUS AOM | OPAO | 48Z | 5.8-5.6 | 3/4 | 0.56 | - | €328.43 | |
 |
048A11O1351 | - | CONTINUOUSAOM | OPAO | 48Y | 2.7 | 1/3 | 0.25 | - | €262.38 |
