LEESON 048A17T2004 X026 / 48A17T2004D General Purpose Farm Duty Motor, 0.50 HP, 1 Phase, 60 Hz, 115/230V, 1800 RPM
Get it by Tuesday, Jun 17
€327.36 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | Poultry Fan Motor |
| Application | Farm Duty |
| Bearing Type | Ball |
| Body Dia. | 5 11/16" |
| Capacitor Required | Yes |
| Duty Cycle | Continuous |
| Efficiency | 70% |
| Extended Thru-bolts | Yes |
| Frame | 48Z |
| Frame Material | Rolled Steel |
| Frequency | 60 Hz |
| Full Load Amps | 6/3A |
| Hp | 1/2 hp |
| Insulation Class | Class B |
| Length Less Shaft | 8 1/4" |
| Max. Ambient Temp. | 40°C |
| Motor Application | Belt Drive Fan/Blower |
| Motor Enclosure Design | Totally Enclosed Air Over |
| Motor Mounting Position | Horizontal |
| Motor Shaft Design | Flat |
| Motor Shaft Rotation | CW/CCW |
| Motor Sub Application | Direct Drive Fan/Blower |
| Motor Type | Permanent Split Capacitor |
| Mounting Type | Cradle Base |
| Nameplate Rpm | 1625 RPM |
| No. Of Speeds | 1 |
| Nominal Efficiency | 68.5% |
| Overall Length | 10 13/16" |
| Phase | 1 |
| Ring Dia. | 2 1/4" |
| Ring To Ring Center | 7 22/25" |
| Rpm Range | 1601-1700 RPM |
| Service Factor | 1 |
| Shaft Dia. | 1/2" |
| Shaft Length | 2 1/2" |
| Stud Pattern | 1 3/25" x 5 3/25" |
| Stud Size | #10-32 |
| Thermal Protection | Automatic |
| Usable @ 200v | No |
| Usable @ 208v | No |
| Voltage | 115/230V AC |
| Hz | 60 Hz |
| Ins. Class | Class B |
| Motor Bearings | Ball |
| Motor Design | Permanent Split Capacitor |
| Motor Frame Material | Steel |
| Motor Mounting Type | Cradle Base |
| Motor Service Factor | 1 |
| Motor Thermal Protection | Auto |
| Standards | CSA CERTIFIED, UL RECOGNIZED |
| Weight | 22 lbs. |
| Ship weight (kg) | 9.9 |
| Ship height (cm) | 20.47 |
| Ship length (cm) | 31.6 |
| Ship width (cm) | 23.19 |
| HS code | 8501404040 |
| Country of Origin | MX |
| Product | Model | Frame | Full Load Amps | HP | Length Less Shaft | Nameplate RPM | Nominal Efficiency | Overall Length | Ring to Ring Center | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
048A11T2021 | 48Y | 3.2/1.6 | 1/4 | 7.5" | 1075 | 59.5% | 10 1/16" | 7.55" | €319.78 | |
 |
048A11T2022 | 48Y | 4.2/2.1 | 1/3 | 8.25" | 1075 | 68% | 10 13/16" | 7-22/25" | €319.71 | |
 |
048A11T2023 | 48Y | 6.4/3.2 | 1/2 | 8.25" | 1075 | 68% | 10 13/16" | 7-22/25" | €342.54 | |
 |
048A17T118 | 48Y | 3.6/1.8 | 1/4 | 8.5" | 1625 | 68% | 11 1/16" | 8-3/25" | €298.20 | |
 |
048A17T119 | 48Y | 5.4/2.7 | 1/2 | 9.25" | 1625 | 72% | 11 13/16" | 8-20/23" | €372.82 | |
 |
048A17T2002 | 48Z | 2.9/1.4 | 1/4 | 7.5" | 1625 | 65% | 10 1/16" | 7.55" | €271.02 | |
 |
048A17T2003 | 48Z | 4.4/2.2 | 1/3 | 7.5" | 1625 | 68.5% | 10 1/16" | 7.55" | €301.47 |
