LEESON 048A17O70 X041 / 48A17O70P Fan and Blower Motor, 0.33 HP, 1 Phase, 60 Hz, 208-230V, 1800 RPM
€86.17 /unit
Request a Quote
Payment
Payment
| Item | HVAC Motor |
| Ambient Temp. | 40°C |
| Assembly | F1 Only |
| Conduit Box Position | F1 Only |
| Duty Cycle | Continuous |
| Efficiency | 66% |
| Enclosure Type | Open Air Over |
| Frame | 48Z |
| Frequency | 60 Hz |
| Full Load Amps | 1.7-1.8A |
| Full Load Efficiency | 66% |
| Hp | 1/3 hp |
| Insulation Class | Class B |
| Max. Ambient Temp. | 40°C |
| Motor Enclosure Design | Open Air Over |
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Resilient Ring Extended Studs |
| Motor Service Factor | 1 |
| Motor Shaft Rotation | Fixed CCW |
| Motor Thermal Protection | Automatic |
| Motor Type | Permanent Split Capacitor |
| Mounting Type | Resilient Ring Extended Studs |
| Nameplate Rpm | 1625 RPM |
| Nema Design | No Design Code |
| Number Of Speeds | 3 |
| Phase | 1 |
| Power | 0.246 kW |
| Rpm | 1625 RPM |
| Service Factor | 1 |
| Shaft Dia. | 1/2" |
| Shaft Length | 7.81" |
| Shaft Orientation | Horizontal |
| Thermal Protection | Automatic |
| Voltage | 208-230V AC |
| Ship weight (kg) | 6.75 |
| Ship height (cm) | 15.24 |
| Ship length (cm) | 55.88 |
| Ship width (cm) | 15.88 |
| HS code | 8501404040 |
| Country of Origin | MX |
| Product | Model | Duty | Frame | Full Load Amps | HP | kW | Mounting | RPM | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
 |
048A11O2028 | CONTINUOUS AOM | 48Z | 5.7-4.5 | 3/4 | 0.56 | Extended Studs - Footless | 1075 | €351.27 | |
 |
048A11O2012 | CONTINUOUSAOM | 48Y | 1.0 | 1/8 | 0.09 | Extended Studs - Footless | 1075 | €95.60 |
