JOHNSON CONTROLS TE-6312P-1 Temperature Sensor Well 8 In
Get it by Tuesday, Jun 17
€86.20 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | Temperature Sensor |
| Compatible With Brand | Johnson Controls |
| Electrical Connection Type | Hardwired |
| For Use With Building Automation Systems | Building Automation System Compatible |
| Housing Color | White |
| Housing Material | Plastic |
| Housing Type | Conduit Box |
| Measurement Type | Single |
| Output | Not Applicable |
| Overall Height | 6" |
| Overall Width | 2 3/4" |
| Probe Length | 8" |
| Sensing Element | Nickel |
| Sensing Element Type | Nickel |
| Sensor Accuracy | -0.34°F to +0.34°F |
| Temp. Accuracy | -0.34°F to +0.34°F |
| Compatible With Manufacturer Model Number | TE-6300P |
| Compatible With Series | TE 6300 |
| Display Type | None |
| Loop Resistance | 1000 ohms |
| Maximum Operating Temperature | 220°F |
| Maximum Sensing Temperature | 220°F |
| Minimum Operating Temperature | -50°F |
| Minimum Sensing Temperature | -50°F |
| Mounting Location | Remote Immersion |
| Product Type | Immersion Temperature Sensor |
| Series | TE-6300P Series |
| Temperature Accuracy | +/-0.34°F |
| Ship weight (kg) | 0.18 |
| Ship height (cm) | 15.16 |
| Ship length (cm) | 6.99 |
| Ship width (cm) | 3.51 |
| HS code | 9025198080 |
| Country of Origin | MX |
| Model | Type | Price | |
|---|---|---|---|
| TE-6311M-1 | Nickel 1k ohm, Duct Mount Metal 8" | €42.06 | |
| TE-6311P-1 | Nickel 1k ohm, Duct Mount Plastic 8" | €175.86 | |
| TE-6311V-2 | Nickel 1k ohm, Flange 8" | €36.15 | |
| TE-6312M-1 | Nickel 1k ohm, Well, Metal, 8" | €73.91 | |
| TE-6314P-1 | Nickel 1k ohm, Wall Mount | €35.27 | |
| TE-6315P-1 | Nickel 1k ohm, Adjustable, Plastic | €172.05 | |
| TE-6316P-1 | Nickel 1k ohm, Adjustable, Plastic | €194.20 |
