| Item | Control |
| Application | Heat And Cool |
| Bulb Dia. | 3/8" |
| Bulb Length | 4" |
| Capillary Length | 72" |
| Changeover Type | Manual |
| Compatible System Type | Condenser Fan Control, Tower Fan Control |
| Control Type | Screwdriver |
| Depth | 3 1/4" |
| Differential Type | Fixed |
| Enclosure Material | Steel |
| Enclosure Nema Rating | NEMA 3R |
| Height | 4 5/8" |
| Max. Control Temp. | 120°F |
| Max. Operating Temp. | 210°F |
| Min. Control Temp. | 40°F |
| Min. Operating Temp. | -35°F |
| Number Of Cooling Stages | 2 |
| Number Of Heating Stages | 2 |
| Overall Depth | 3 1/4" |
| Overall Height | 4 5/8" |
| Overall Width | 4 5/8" |
| Switch Action | Open On Rise/Close On Rise |
| Switch Type | SPDT |
| Temperature Scale | Fahrenheit |
| Thermostat Type | Weatherproof Two Stage Controls |
| Voltage | 24-277V AC |
| Width | 4 5/8" |
| Bulb Diameter | 3/8" |
| Maximum Control Temperature | 120°F |
| Maximum Operating Temperature | 210°F |
| Minimum Control Temperature | 40°F |
| Minimum Operating Temperature | -35°F |
| Temperature Differential | 8°F, 5°F |
| Ship weight (kg) | 1.22 |
| Ship height (cm) | 11.75 |
| Ship length (cm) | 8.26 |
| Ship width (cm) | 11.75 |
| Country of Origin | MX |
