| Collet Capacity - Maximum | 1" |
| Collet Capacity - Minimum | 1/8" |
| Column Width | 14 1/4" |
| Cross Travel - Maximum | 15 5/16" |
| Current | 6.5/13A |
| Drawbar Style | Manual |
| Frequency | 60 Hz |
| Head Swivel - Left | 90° |
| Head Swivel - Right | 90° |
| Head Tilt - Backward | 45° |
| Head Tilt - Forward | 45° |
| Horsepower | 5 hp |
| Knee Travel - Maximum | 19 1/4" |
| Longitudinal Travel - Maximum | 33 7/8" |
| Milling Head Drive | Belt Drive |
| Motor Speed - Maximum | 1720 RPM |
| Motor Type | Totally Enclosed Fan-Cooled |
| Number Of Spindle Speeds | Variable |
| Number Of T-slots | 3 |
| Overall Depth | 59" |
| Overall Height | 96 1/2" |
| Overall Width | 82" |
| Phase | Three |
| Quill Diameter | 3 3/8" |
| Ram Travel - Maximum | 25" |
| Right-hand Head Tilt | 90° |
| Series | JTM-1254RVS |
| Sound Level | 72 dbA |
| Spindle Speed - Maximum | 3800 RPM |
| Spindle Speed - Minimum | 80 RPM |
| Spindle Taper | R8 |
| Spindle Travel - Maximum | 5" |
| Spindle-to-column Distance - Maximum | 27 3/4" |
| Spindle-to-column Distance - Minimum | 7 1/2" |
| Spindle-to-table Distance | 23" |
| T-slot Depth | 3/4" |
| T-slot Width | 5/8" |
| Table Depth | 12" |
| Table Load Capacity | 925 lbs. |
| Table Width | 54" |
| Voltage | 230/460V |
| Ship weight (kg) | 733.5 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 234 |
| Ship width (cm) | 202.88 |
| Country of Origin | TW |
