| Item | Relay |
| Air Capacity | 0.039 SCFM |
| Body Material | Plastic |
| Contact Form | SPDT |
| Control Action | Direct Acting |
| Diaphragm Material | Neoprene |
| Differential Adjustability | Fixed |
| Differential Pressure - Maximum | 0.5 psi |
| Main Port Connection Size | 1/4" |
| Main Port Connection Type | Barbed Hose |
| Maximum Safe Air Pressure | 30 psi |
| Mounting Style | Inline, Panel |
| Number Of Port Connections | 4 |
| Operating Humidity - Minimum | 5% |
| Operating Pressure - Maximum | 18 psi |
| Operating Pressure - Minimum | 0 psi |
| Operating Temperature - Maximum | 140°F |
| Operating Temperature - Minimum | 0°F |
| Overall Depth | 1 1/2" |
| Pilot Port Connection Size | 1 1/4" |
| Pilot Port Connection Type | Barbed Hose |
| Pilot Pressure - Maximum | 15 psi |
| Pilot Pressure - Minimum | 3 psi |
| Port Types Included | Branch, Exhaust, Main/Supply, Pilot |
| Relay Type | Capacity |
| Selector Type | Higher of Two Pressures |
| Setpoint Pressure - Maximum | 15 psi |
| Setpoint Pressure - Minimum | 3 psi |
| Start Point Adjustment Pressure - Maximum | 15 psi |
| Start Point Adjustment Pressure - Minimum | 3 psi |
| Supply Pressure Max. | 18 psi |
| Ship weight (kg) | 0.02 |
| Product | Model | Construction | Control Range | Depth | Diameter | Pressure Range | Price | |
|---|---|---|---|---|---|---|---|---|
 |
RP419A1057 | - | - | - | - | - | €779.02 | |
|
RP419A1107 | - | - | - | - | - | €918.76 | |
|
RP419B1071 | - | - | - | - | - | €952.96 | |
 |
RP470A1003 | Molded Plastic | 0 to 18 psi | 1" | 1 1/2 | 0 to 18 psi | €130.51 | |
 |
RP471A1002 | - | - | - | - | - | €332.61 | |
 |
RP670A1001 | - | - | - | - | - | €232.46 | |
 |
RP670B1017 | - | - | - | - | - | €446.72 |
