| Item | Relay |
| Air Capacity | 0.039 SCFM |
| Body Material | Plastic |
| Branch Port Connection Size | Not Applicable |
| Branch Port Connection Type | Not Applicable |
| Common Port Connection Size | Not Applicable |
| Common Port Connection Type | Not Applicable |
| Construction | Molded Plastic |
| Control Action | Direct Acting |
| Control Range | 0 psi to 18 psi |
| Control Type | Selector Relay |
| Depth | 1" |
| Differential Adjustability | Fixed |
| Differential Pressure - Maximum | 0.5 psi |
| Differential Pressure - Minimum | Not Applicable |
| Exhaust Port Connection Size | Not Applicable |
| Exhaust Port Connection Type | Not Applicable |
| Includes | Mounting Clip |
| Input Pressure | Not Applicable |
| Input Pressure - Minimum | Not Applicable |
| Main Port Connection Size | Not Applicable |
| Main Port Connection Type | Not Applicable |
| Max. Operating Span Adjustment Pressure | Not Applicable |
| Max. Pilot Pressure | Not Applicable |
| Max. Safe Air Psi | 30 psi |
| Maximum Safe Air Pressure | 30 psi |
| Mounting Style | Inline, Panel |
| Normally Connected Port Connection Size | Not Applicable |
| Normally Connected Port Connection Type | Not Applicable |
| Normally Disconnected Port Connection Size | Not Applicable |
| Normally Disconnected Port Connection Type | Not Applicable |
| Number Of Port Connections | 3 |
| Operating Range - Max. | 18 psi |
| Overall Depth | 1" |
| Pilot Port Connection Size | 5/32" |
| Pilot Port Connection Type | Barbed Hose |
| Pilot Pressure - Minimum | Not Applicable |
| Port Types Included | Branch, Pilot |
| Pressure Range | 0 psi to 18 psi |
| Pressure Rating | 0 psi to 18 psi |
| Response Pressure | 0.015 psi |
| Setpoint Adjustability | Fixed |
| Setpoint Pressure - Max. | 15 psi |
| Setpoint Pressure - Minimum | 3 psi |
| Start Point Adjustment Pressure | 15 psi |
| Start Point Adjustment Pressure - Min. | 3 psi |
| Supply Pressure - Maximum | Not Applicable |
| Switching Ranges | Not Applicable |
| Contact Form | SPDT |
| Control Signal | Multi-Functional Technology |
| Operating Pressure - Maximum | 18 psi |
| Operating Pressure - Minimum | 0 psi |
| Operating Temperature - Maximum | 140°F |
| Operating Temperature - Minimum | 0°F |
| Relay Type | Selector Higher of Two |
| Selector Type | Higher of Two Pressures |
| Setpoint Pressure - Maximum | 15 psi |
| Start Point Adjustment Pressure - Maximum | 15 psi |
| Start Point Adjustment Pressure - Minimum | 3 psi |
| Ship weight (kg) | 0.03 |
| Country of Origin | USA |
| Product | Model | Construction | Control Range | Depth | Diameter | Pressure Range | Price | |
|---|---|---|---|---|---|---|---|---|
 |
RP419A1057 | - | - | - | - | - | €779.02 | |
|
RP419A1107 | - | - | - | - | - | €918.76 | |
|
RP419B1071 | - | - | - | - | - | €952.96 | |
 |
RP471A1002 | - | - | - | - | - | €332.61 | |
 |
RP670A1001 | - | - | - | - | - | €232.46 | |
 |
RP670B1017 | - | - | - | - | - | €446.72 | |
 |
RP819B1002 | - | - | - | - | - | €849.63 |
